TLS-450 Setup and Operation Screens Manual
282
Probe Diagnostics - Channel
The Probe Diagnostics - Channel screen displays a report with Channel data information for each probe.
Report Description
Each probe's channel data is preceded by the following header information:
• Probe label (e.g., 1) and type (e.g., Mag 1)
• Probe serial number (up to 7 digits)
• Date and time (time channel data was received)
• Channel Data - Label for the Channel Section
Channel data (Hex number) is read from the report as shown in the example below:
In the example above, the last sample for Channel 0 is B610, for Channel 3 it is 0235, and for channel 16
it is 00A1.
