TLS-450 Setup and Operation Screens Manual

292

Status

External Input State

Possible messages: Active, Inactive

Duration

Time the External Input has been in the current state.

Value range: 0000 to 9999 days plus hh:mm:ss (e.g., 00001 03:05:48)

Type

The External Input type.

Possible messages:

• Standard

• Generator

• Pump Sense

• Standard ACK

External Input Diagnostic Screen Refresh Rate

The External Input data will be updated on change of state.

Control Button (right of screen)

Setup

Touch this button to open the "Device Setup - External Inputs

" screen.
