TLS-450 Setup and Operation Screens Manual

300

• Containment Sump

Sample Counter

Sensor Sample Counter value

Value range: 0 to 99

Value

Resistance or current value

Value range: 0 to 1000000000 (Resistance Value) or 0.0 to 50.0 (Current Value in microamps)

Status

Sensor Status

Possible messages:

• Normal

• Unknown

• Setup Data Warning

• Fuel Alarm

• Out Alarm

• Short Alarm

• Water Alarm

• Water Out Alarm

• High Liquid Alarm

• Low Liquid Alarm

• Liquid Warning

Sensor Diagnostics 2-Wire CL Sensor Refresh Rate

The 2-Wire CL Sensor Diagnostics data will be refreshed every 5 seconds.

Control Button (right of screen)

Setup

Touch this button open the Device Setup – Type A Sensor (2-Wire CL)

screen.

Table of Contents3
Introduction12
- Contractor Certification Requirements12
- Related Manuals12
- Safety Precautions12
- Safety Warnings13
Front Panel Layout14
- Item 1 - Integral Printer14
- Item 2 - System Visual Status Leds14
- Item 3 - Touch Screen14
Navigating the Touch Screens15
- Setup, Operation, Diagnostic Touch Screen Layout17
- Online Help Touch Screen Layout19
Entering Data20
- Changing/Editing Values in a Field20
- Specialty Dialog Keypads21
Initial Console Setup Sequence25
- Initial Startup Procedure25
- Startup Display25
Understanding Alarms27
- What Happens When an Alarm Is Posted27
- How Do I Silence the Console Beeper and Acknowledge the Alarm27
- How Do I Learn more about an Alarm and What to Do about It28
Changing Printer Paper31
Setup Screens32
Main Setup32
Date and Time Setup33
- Date & Time Setup - Daylight Savings33
Date & Time Setup - Date & Time Set35
Display Setup - Language and Units36
Display Setup - Date & Time Format37
Display Setup - Number Format38
Display Setup - System Status39
Display - All Tanks - All Tanks Tab Advanced Setup41
Display - All Tanks - Fuel Fill Selection43
Display Setup - All Sensors Tab Advanced Setup44
- Liquid Sensors44
- Type a (2-Wire CL) Sensors45
- Type B (3-Wire CL) Sensors45
- Mag Sensors45
- Ground Water Sensors46
- Vapor Sensors46
- Alarm Condition Icon46
- Line Pressure Sensors47
User Defined 1-3 Tabs48
- Display Setup - User Defined 1 - 3 Tabs48
Headers Setup49
Security - System Security51
Device Setup - Probes53
Device Setup - Relays56
Device Setup - External Inputs58
Device Setup - Liquid Sensor60
Device Setup - Type a Sensor62
Device Setup - Type B Sensor64
Device Setup - Mag Sensor66
Device Setup - Groundwater Sensor68
Device Setup - Vapor Sensor69
Device Setup - Line Pressure Sensor71
Device Setup - LV/MDIM72
Tank Setup - General74
Tank Setup - Limits78
Tank Setup - Environmental Tests83
Tank Setup - All Tanks89
Tank Setup - Product92
- Report Column Descriptions92
- Control Buttons (Right Side of Screen)92
Tank Setup - Product Mapping94
- Report Column Descriptions94
- Control Buttons (Right Side of Screen)94
Tank Setup - View All Products96
Tank Setup - Chart97
Tank Setup - Manual Calibration99
- Adding a New Manually Calibrated Tank Chart100
- Control Buttons (Right of Screen)103
Tank Setup - Tank Charts105
- Control Buttons (Right of Screen)106
Tank Setup - Siphon Sets107
Tank Setup - Accuchart II109
Pumps and Lines112
PLLD Setup Overview112
Pumps and Lines Setup - Pumps113
Pumps and Lines Setup - Lines115
Pumps and Lines Setup - All Lines117
- Line Lockout Schedule - Daily117
- Line Lockout Schedule - Individual118
Pumps and Lines Setup - All PLLD119
Pumps and Lines Setup - PLLD121
Custom Alarms125
Custom Alarms Setup - Enable125
Custom Alarms Setup - View126
- Report Column Descriptions126
Custom Alarms - Setup128
- Control Button (on Right of Screen)129
Custom Help130
Custom Help Setup - Enable130
Custom Help Setup - Alarms131
- Control Buttons (on Right of Screen)131
Inventory132
Inventory Setup - Shift Close Method132
Inventory Setup - Shift Times134
Inventory Setup - Inventory Report Times135
Delivery136
Delivery Setup136
Reconciliation137
Reconciliation Setup - General137
Reconciliation Setup - Threshold Alarms139
Comm142
Comm Setup - General142
- Console Comm Device Permissible Slots and Configurable Ports142
- Comm Setup Procedure144
RS-232/RS-485, Internal Modem, Satellite Hughes H-Jbox and Satellite S-Sat Comm Devices - General145
- Ethernet Comm Devices - General147
- Ethernet Comm Devices - General149
Comm Setup - Modem151
EDIM Comm Devices - General152
- EDIM Comm Devices - General153
(EDIM) Comm Setup - DIM155
CDIM Comm Devices - General156
- CDIM Comm Devices - General157
Comm Setup - Advanced159
- RS-232/RS-485, Internal Modem, Satellite Hughes H-Jbox, Satellite S-Sat and Ethernet Comm Devices - Advanced Tab Setups159
- EDIM Advanced Tab Setups160
- CDIM Advanced Tab Setups161
- CDIM Advanced Tab Setups162
Comm Setup - All Comms163
Automatic Events164
Automatic Events Setup - Address Book164
- Report Column Descriptions164
- Control Buttons (on Right of Screen)165
Add/Edit Contact Entry - Contacts166
- Control Buttons (Lower Right of Screen)166
Add/Edit Contact Entry - Modem167
- Control Buttons (Lower Right of Screen)168
Add/Edit Contact Entry - Fax169
- Control Buttons (Lower Right of Screen)170
Add/Edit Contact Entry - TCP/IP171
- Control Buttons (Lower Right of Screen)172
Add/Edit Contact Entry - Satellite173
- Control Buttons (Lower Right of Screen)174
Add/Edit Contact Entry - Email175
- Control Buttons (Lower Right of Screen)175
Automatic Events Setup - Task Log176
- Report Column Descriptions176
- Control Buttons (on Right of Screen)177
Automatic Events Setup - All Tasks178
- Report Column Descriptions178
- Control Buttons (on Right of Screen)179
Automatic Events Setup - Device Tasks180
- Report Column Descriptions180
- Control Buttons (on Right of Screen)181
Automatic Events - Add Tasks - Device182
Automatic Events Setup - Print Tasks183
- Report Column Descriptions183
- Control Buttons (on Right of Screen)184
Automatic Events Add Tasks - Print185
Automatic Events Setup - Auto Connect Tasks187
- Report Column Descriptions187
- Control Buttons (on Right of Screen)188
Automatic Events - Add Tasks - Auto Connect189
Meter191
Meter Setup191
Printer Setup - Setup192
- Printer Setup Screen 1192
- Printer Setup Screen 2193
- Setup a Printer with the Get Printers Button193
- Setup a Network Printer with URI Field194
- Removing Printers194
Printer Setup - Status195
Printer Setup - Jobs197
Reports198
Active Alarm Report198
- Report Column Descriptions198
- Active Alarm Report Screen Refresh Rate199
- Control Button (on Right of Screen)199
Alarm History Report200
- Report Column Descriptions200
- Control Buttons (on Right of Screen)201
Priority Alarm History Report202
- Report Column Descriptions202
- Control Buttons (on Right of Screen)203
Non-Priority Alarm History Report204
- Report Column Descriptions204
- Control Buttons (on Right of Screen)205
Inventory Reports206
Inventory Reports - Current Inventory206
- Report Column Descriptions206
- Current Inventory Report Screen Refresh Rate207
Inventory Reports - Inventory History208
- Report Column Descriptions208
- Control Button (on Right of Screen)209
Inventory Reports - Shift Inventory210
- Report Column Descriptions210
Environmental Reports212
Environmental Reports - Combined Tank Test212
- Report Column Descriptions213
- Control Buttons (on Right of Screen)213
- Regulatory Compliance213
Line Leak Report Passed Test Results214
- Report Column Descriptions214
- Control Button (on Right of Screen)215
Environmental Reports - Sensor Status216
- Report Column Descriptions216
Environmental Reports - Sensor Status History218
- Screen Title Bar218
- Report Column Descriptions218
- Control Buttons (on Right of Screen)219
Delivery Reports221
Delivery Report - Manual Delivery221
- Report Column Descriptions221
- Control Buttons (Right Side of Screen)222
Last Delivery Report223
- Report Column Descriptions224
Delivery History Report225
- Report Column Descriptions225
- Control Button (on Right of Screen)226
Delivery Report - Ticketed Delivery Report227
- Control Button (on Right of Screen)228
Edit Delivery Ticket229
- Control Button (on Right of Screen)230
Add Delivery Ticket231
Delivery Report - Adjusted Delivery Report233
- Report Column Descriptions233
- Control Button (on Right of Screen)234
BIR Reports235
Reconciliation Report - Reconciliation235
- Report Column Descriptions236
- Control Buttons (on Right Side of Screen)236
Reconciliation Reports - Book Variance Report239
- Report Column Descriptions240
- Control Buttons (on Right Side of Screen)240
Reconciliation Reports - Reconciliation Test Report242
- Report Column Descriptions242
- Control Buttons (on Right Side of Screen)243
Diagnostic Screens244
Diagnostics Main Screen244
Tank Test Diagnostics245
Tank Test Diagnostics - CSLD Test Status245
- Report Column Descriptions245
- CSLD Test Status Refresh Rate246
- Regulatory Compliance246
Tank Test Diagnostics - CSLD Rate Table247
- Report Column Descriptions247
- Control Buttons (Right of Screen)248
- Regulatory Compliance249
Tank Test Diagnostics - CSLD Monthly250
- Report Column Descriptions250
- CSLD Monthly Report Refresh Rate251
- Control Buttons (on Right of Screen)251
- Regulatory Compliance251
Tank Test Diagnostics - SLD Last Test252
- Report Column Descriptions252
- Control Buttons (Right of Screen)253
- Regulatory Compliance253
Tank Test Diagnostics - SLD In-Progress254
- Report Column Descriptions254
- SLD Test In-Progress Report Refresh Rate256
- Test Control Buttons (on Right of Screen)256
- Regulatory Compliance256
Manual Static Leak Detect Screen257
- Test Control Buttons (on Right of Screen)258
Tank Test Diagnostics - SLD History259
- Report Column Descriptions259
- SLD History Report Refresh Rate260
- Control Buttons (Right of Screen)260
- Regulatory Compliance260
Pumps and Lines261
PLLD Diagnostics - Manual Test261
- Report Column Descriptions262
- PLLD Manual Test - Refresh Rate262
- Test Control Buttons (on Right of Screen)262
PLLD Diagnostics - PLLD Status263
- Report Column Descriptions263
- PLLD Status - Refresh Rate264
- Control Buttons (Right of Screen)264
PLLD Diagnostics - 3.0 Gph (11.3Lph) Test Results265
- Report Column Descriptions265
- Control Buttons (Right of Screen)266
PLLD Diagnostics - MID-Range Test Results267
- Report Column Descriptions267
- Control Buttons (Right of Screen)268
PLLD Diagnostics - No-Vent Aborts269
- Report Column Descriptions269
- Control Buttons (Right of Screen)270
PLLD Diagnostics - 0.2 Gph (0.76 Lph) Test Results271
- Report Column Descriptions271
- Control Buttons (Right of Screen)272
PLLD Diagnostics - 0.1 Gph (0.38Lph) Test Results273
- Report Column Descriptions273
- Control Buttons (Right of Screen)274
Tank275
Tank Diagnostics - 30 Second Inventory Samples275
- Report Column Descriptions275
- 30 Second Inventory Samples Refresh Rate276
Meter277
Meter Diagnostics - Meter Events277
- Control Button (Right Side of Screen)278
Meter Diagnostics - Tank Map279
- Control Buttons (Right Side of Screen)280
- Clear All281
Meter Diagnostics - Manual Mapping282
- Report Column Descriptions282
- Control Buttons (Right Side of Screen)283
Reconciliation284
Reconciliation Diagnostics - Status284
- Report Column Description284
- Control Buttons (on Right Side of Screen)285
Reconciliation Diagnostics - Reconciliation286
- Report Column Descriptions287
- Control Buttons (on Right Side of Screen)288
Probe289
Probe Diagnostics - General289
- Report Column Descriptions289
- Probe Diagnostics - General Screen Refresh Rate290
- Control Button (Right of Screen)290
Probe Diagnostics - Reference Distance291
- Report Column Descriptions291
- Probe Diagnostics - Reference Distance Screen Refresh Rate292
- Control Buttons (Right of Screen)292
Probe Diagnostics - Channel293
- Report Description293
- Probe Diagnostics Channel Refresh Rate294
- Control Button (Right of Screen)294
Probe Diagnostics - Mag Options295
- Report Column Descriptions295
- Probe Diagnostics - Mag Options Screen Refresh Rate296
- Control Button (Right of Screen)296
Probe Diagnostics - Communication297
- Report Column Descriptions297
- Probe Diagnostics - Communication Refresh Rate298
- Control Button (Right of Screen)298
Relays & Inputs299
Relays and External Inputs Diagnostics - Relays299
- Column Descriptions300
- Control Buttons (Right of Screen)300
- Sequential Testing Procedure300
- Inspection Testing Procedure301
Relays and External Inputs Diagnostics - External Inputs302
- Report Column Descriptions302
- External Input Diagnostic Screen Refresh Rate303
- Control Button (Right of Screen)303
Sensor304
Sensor Diagnostics - Liquid304
- Report Column Descriptions304
- Sensor Diagnostics Liquid Sensor Refresh Rate305
- Control Button (Right of Screen)305
Sensor Diagnostics - Vapor306
- Report Column Descriptions306
- Sensor Diagnostics Vapor Sensor Refresh Rate307
- Control Button (Right of Screen)307
Sensor Diagnostics - Groundwater308
- Report Column Descriptions308
- Sensor Diagnostics Groundwater Sensor Refresh Rate309
- Control Button (Right of Screen)309
Sensor Diagnostics - 2-Wire CL310
- Report Column Descriptions310
- Sensor Diagnostics 2-Wire CL Sensor Refresh Rate311
- Control Button (Right of Screen)311
Sensor Diagnostics - 3-Wire CL312
- Report Column Descriptions312
- Sensor Diagnostics 3-Wire CL Sensor Refresh Rate313
- Control Button (Right of Screen)313
Mag Sensor314
Mag Sensor Diagnostics - General314
- Report Column Descriptions314
- Mag Sensor Diagnostics - General Screen Refresh Rate315
- Control Button (Right of Screen)315
Mag Sensor Diagnostics - Comm316
- Report Column Descriptions316
- Mag Sensor Diagnostics - Comm Screen Refresh Rate317
- Control Button (Right of Screen)317
Mag Sensor Diagnostics - Constants318
- Report Column Descriptions318
- Control Buttons (Right of Screen)319
Mag Sensor Diagnostics - Channel320
- Report Description320
- Mag Sensor Diagnostics - Channel Screen Refresh Rate321
- Control Buttons (Right of Screen)321
Line Pressure Sensor322
LPR Sensor Diagnostics - General322
- Report Column Descriptions322
- Diagnostics - LPR Sensor - General Screen Refresh Rate323
- Control Buttons (Right of Screen)323
LPR Sensor Diagnostics - Communications324
- Report Column Descriptions324
- Diagnostics - LPR Sensor - Comm Screen Refresh Rate325
- Control Buttons (Right of Screen)325
LPR Sensor Diagnostics - Constants326
- Report Column Descriptions326
- Control Buttons (Right of Screen)327
LPR Sensor Diagnostics - Channel328
- Report Description328
- Diagnostics - Line Pressure Sensor - Channel Screen Refresh Rate329
- Control Buttons (Right of Screen)329
Accuchart II330
Accuchart II Diagnostics - Delivery Instructions330
- Report Column Descriptions330
Accuchart II Diagnostics - Time Ordered Comparison331
- Report Column Descriptions331
- Control Buttons (Right Side of Screen)332
Accuchart II Diagnostics - Histogram Comparison333
- Control Buttons (Right Side of Screen)333
Accuchart II Diagnostics - Error Plot Comparison334
- Control Buttons (Right Side of Screen)334
Accuchart II Diagnostics - Calibration Feedback335
- Report Column Descriptions335
Accuchart II Diagnostics - Data Sufficiency337
- Control Buttons (Right Side of Screen)338
Modules339
Module Diagnostics - Hardware Configuration339
- Report Column Descriptions339
Module Diagnostics - Device Directory341
- Report Column Descriptions341
Module Diagnostics - Device Assignments342
- Report Column Descriptions342
Module Diagnostics - Comm344
- Report Column Descriptions344
- Control Buttons (Right of Screen)345
Module Diagnostics - Firmware Upgrade346
- Report Column Descriptions346
- Control Buttons (Right Side of Screen)347
Software Maintenance348
Connecting USB Thumb Drive for Software Maintenance Procedures348
Software Maintenance - Backup Restore351
- Backup/Restore Screen Fields and Buttons351
Software Maintenance - Download353
- Download Procedure353
- Download Screen Fields and Buttons354
- Control Buttons (Right Side of Screen)354
Software Maintenance - Install355
- Installation Procedure355
- Install Screen Fields356
- Control Button (Right Side of Screen)356
About357
- About - System Screen357
Specialty Dialog Screens358
Alpha Keypad Dialog358
Enhanced Numeric Keypad Dialog359
Numeric Keypad Dialog360
Report Range Selection Dialogs361
Periodic Maintenance Checklist362
References366
DIM Information Tables366
Table of Acronyms369
Table of Alert Symbols371
Table of Device Identifiers372
Table of Module Device Identifiers373
Table of Standard Abbreviations373
Table of Unit Abbreviations374
Table of Unit Conversions375
Table of Mag Probe Features375

Brand	Veeder-Root
Model	TLS-450
Category	Music Mixer
Language	English

Veeder-Root TLS-450 Setup And Operation

Table of Contents

Other manuals for Veeder-Root TLS-450

Questions and Answers:

Veeder-Root TLS-450 Specifications

Related product manuals
