TLS-450 Setup and Operation Screens Manual
356
NOTES:
1. Parameter string is never required.
2. Will not generate Comm Alarm.
3. Metric is the default setting for unit conversion. Requires 'G' in parameter string for gallon units.
4. A two port CDIM. Normal CDIMs have 3 ports - CDIMII has two ports that monitor two comm channels each.
5. No blending.
6. Use 'P' in parameter string for Tokheim 2+1, 3+1 and 4+1 blending dispensers.
7. DIMs implemented for V402.
8. Non-U.S. DIM.
DIM Specific Parameters
STRING
DESCRIPTION
GILBARCO GSITE (Pass Through)
None
GILBARCO CL
T
Do not collect cumulative totals
R
Send captured message to TLS (Engr. use only)
W
Transaction field precision is hundredths (thousandths default)
C
Cumulative field precision is hundredths (thousandths default)
TOKHEIM 67A&B
T
Blender only site - collects only blender messages
R
Send captured message to TLS (Engr. use only)
P
Plus one dispensers at site - use plus one algorithm
TOKHEIM DHC
T
Tank volume enabled. TLS will report to DHC tank volumes
WAYNE CL
R
Send protocol to TLS (Engr. use only)
SCHLUMBERGER
R
Send protocol to TLS (Engr. use only)
SCHLUMBERGER SAM
T
Send protocol of controller transmit line to TLS (Engr. use only)
R
Send protocol of controller receiver line to TLS (Engr. use only)
GASBOY RS422
None
GASBOY CFN
None
V-R PROTOCOL (BIR) (Pass Through)
J
Suppress Comm Alarm
MECHANICAL
L
Pulse out loop-back signal
(see Pulse Conversion Parameters Table)
LOW VOLT MECHANICAL
L
Pulse out loop-back signal
(see Pulse Conversion Parameters Table)
