102 CoDeSys 2.3 Runtime Environment WAGO-I/O-SYSTEM 750
758-874/000-131 WAGO-I/O-IPC-C6
Manual
Version 1.0.0
11.4 Addressing Example
The following addressing example clarifies the access to the process image:
Table 53: Arrangement of the I/O modules for the addressing example
I/O-IPC 750-
400
1
750-
554
2
750-
402
3
750-
504
4
750-
454
5
750-
650
6
750-
468
7
750-
600
8
Table 54: Addressing example
I/O Module Input Data Output Data Description
Type
C*
1 %IX8.0
750-400
2 %IX8.1
2DI, 24 V, 3 ms:
1. Digital I/O module with a data width of
2 bits. Since the analog input modules
already occupy the first 8 words of the input
process image, the 2 bits occupy the lowest-
value bits of the 8th word.
1 %QW0
750-554
2 %QW1
2AO, 4 – 20 mA:
1. Analog output module with a data width of
2 words. This module occupies the first 2
words in the output process image.
1 %IX8.2
2 %IX8.3
3 %IX8.4
750-402
4 %IX8.5
4DI, 24 V:
2. Digital input module with a data width of 4
bits. These are added to the 2 bits of the 750-
400 and stored in the 8th word of the input
process image.
1 %QX4.0
2 %QX4.1
3 %QX4.2
750-504
4 %QX4.3
4DO, 24 V:
1. Digital output module with a data width of
4 bits. Since the analog output module
already occupies the first 4 words of the
output process image, the 4 bits occupy the
lowest-value bits of the 4th word.
1 %IW0
750-454
2 %IW1
2AI, 4 – 20 mA:
1. Analog input module with a data width of
2 words. This module occupies the first 2
words in the input process image.
%IW2
%IW3
%QW2
750-650
1
%QW3
RS232, C 9600/8/N/1:
The serial interface module is an analog input
and output module, which displays 2 words
apiece both in the input process image as
well as in the output process image.
1 %IW4
2 %IW5
3 %IW6
750-468
4 %IW7
4AI, 0 – 10 V S.E:
2. Analog input module with a data width of
4 words. Since the 750-454 and 750-650
analog input and output modules already
occupy the first 4 words of the input process
image, the 4 words of this I/O module are
added behind the others.
