In the operating mode with suppressible mailbox (Mode 2), the mailbox and the
cyclical process data are mapped next.
The following words contain the remaining process dat.
The mailbox and the process image sizes are set with the startup tool WAGO-I/O-
CHECK.
Table 124: AS-interface Master module 750-655
Input and Output Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 - C0/S0 not used
Control/status
byte
1 D1 D0
2 D3 D2
3 D5 D4
... ... ...
max.
23
D45 D44
Mailbox (0, 3, 5, 6 or 9 words)/
Process data (0-16 words)
