Table 74: Operating reports of ERR and STA LED
ERR (39) STA (40)
Color/Status Color/Status
Explanation/Remedy
Off
Off
PROFIBUS master is not configured or has
not received the token from the PROFIBUS
network.
Off
Green
PROFIBUS master holds the token and is
ready to send telegrams
Red
Off
PROFIBUS master has a short circuit.
Red
Green
Communication problem between the
PROFIBUS master and at least one
PROFIBUS-DP slave.
Off Green flashing
(irregular)
PROFIBUS master exchanges the token with
another master in the PROFIBUS network.
