4.4 Battery
Pos: 32.30 /Serie 758 ( Funk, IPC und PFC)/Geräteb eschreibung/Batter ie/Batterie 758-87 x CR2025 @ 10\mod_1314684160 789_21.doc @ 77496 @ @ 1
The 3 V battery (52) of type CR2025 (LiMnO
2
, ca.165 mAh) is located
underneath the screwed down cover (51).
Pos: 32.31 /Serie 758 ( Funk, IPC und PFC)/Geräteb eschreibung/Batter ie/Batterie 758-87 x allgemein @ 10\mod_131236 7434378_21.doc @ 75738 @ @ 1
The battery continues to provide power for the real-time clock (RTC) and volatile
storage (SRAM) with the CoDeSys retain variables if there is a power failure.
You can obtain additional information in Section "Maintenance".
Pos: 32.32 /Serie 758 ( Funk, IPC und PFC)/Geräteb eschreibung/Batter ie/Batterie 758-87 x - Bild @ 10\mod_13147906283 03_21.doc @ 77926 @ @ 1
U1
IDE/PWR
IO
ERR
STA
RDY
RUN
U2
Figure 4: Battery
Pos: 32.33 /Dokumenta tion allgemein/Glied erungselemente/---Seitenwechsel--- @ 3\mod_1221108045078_0.doc @ 21810 @ @ 1
51 52
