146 PROFIBUS Master in CoDeSys 2.3 WAGO-I/O-SYSTEM 750
758-874/000-131 WAGO-I/O-IPC-C6
Manual
Version 1.0.0
Input/Output
Figure 71: "Input/Output" tab
The following table explains the parameters listed in the register:
Table 64: Description of the Parameters
Input/Output
Select >> Using this button, transfer the selected 75x components from the
left window to the right window in order to copy the topology of
the 750 station there.
First add the object "No process data channel" to the right
window. You can find the object in the left column under
"Empty modules".
<<Delete Use this button to remove the added 75x components from the
right window.
Properties Use this button to adjust certain properties of an I/O module
(diagnostics, replacement values, ...).
