WAGO-I/O-SYSTEM 750 I/O Modules 239
758-874/000-131 WAGO-I/O-IPC-C6
Manual
Version 1.0.0
18.2.5.2 Pulse Width Modules
750-511, (and all variations /xxx-xxx)
The above Pulse Width modules have a total of 6 bytes of user data in both the
Input and Output Process Image (4 bytes of channel data and 2 bytes of control/
status). The two channel values are supplied as 16 bits. Each channel has its own
control/status byte. The following table illustrates the Input and Output Process
Image, which has a total of 4 words mapped into each image. Word alignment is
applied.
Table 106: Pulse Width Modules 750-511, /xxx-xxx
Input and Output Process
Byte Destination
Offset
High Byte Low Byte
Description
0 - C0/S0 Control/Status byte of Channel 1
1 D1 D0 Data Value of Channel 1
2 - C1/S1 Control/Status byte of Channel 2
3 D3 D2 Data Value of Channel 2
18.2.5.3 Serial Interface Modules with alternative Data Format
750-650, (and the variations /000-002, -004, -006, -009, -010, -011, -012, -013),
750-651, (and the variations /000-001, -002, -003),
750-653, (and the variations /000-002, -007),
753-650, -653
The process image of the / 003-000-variants depends on the parameterized
operating mode!
With the freely parameterizable variations /003 000 of the serial interface
modules, the desired operation mode can be set. Dependent on it, the process
image of these modules is then the same, as from the appropriate variation.
The above Serial Interface Modules with alternative data format have a total of 4
bytes of user data in both the Input and Output Process Image (3 bytes of serial
data and 1 byte of control/status). The following table illustrates the Input and
Output Process Image, which have a total of 2 words mapped into each image.
Word alignment is applied.
Table 107: Serial Interface Modules with alternative Data Format
Input and Output Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 D0 C/S Data byte
Control/status
byte
1 D2 D1 Data bytes
