Table 72: I/O-IPC Operational Messages
Position LED Color/Status Cause Explanation/Remedy
Yellow
-
I/O-IPC is ready for
operation.
41 RDY
Green flashing
(irregular)
There is a system
error in the
PROFIBUS
controller.
Restart the I/O-IPC. If
this malfunction
recurs, contact
WAGO support.
Green The I/O-IPC has
established at least
one connection to a
configured
PROFIBUS slave.
-
You have stopped
communication with
the slave (ERR LED
also lights up).
-
Green flashing
(5 Hz)
The I/O-IPC cannot
communicate with the
slaves.
Check the cables to
the slaves and check
these for
malfunctions.
42 RUN
Green flashing
(irregular)
There is a missing or
defective
configuration of the
PROFIBUS or a time
error of the host
watchdog has
occurred.
Check the CoDeSys
configuration.
