10.4 Addressing Example
The following addressing example clarifies the access to the process image:
Table 49: Arrangement of the I/O modules for the addressing example
I/O-IPC 750-
400
1
750-
554
2
750-
402
3
750-
504
4
750-
454
5
750-
650
6
750-
468
7
750-
600
8
Table 50: Addressing example
I/O Module Input Data Output Data Description
Type C* FC3,
FC4
FC1,
FC2
FC6 FC5
1 0008 00000
750-400
2 00001
2DI, 24 V, 3 ms:
1. Digital I/O module with a data width of
2 bits. Since the analog input modules already
occupy the first 8 words of the input process
image, the 2 bits occupy the lowest-value bits
of the 8th word.
1 00000
750-554
2 00001
2AO, 4 – 20 mA:
1. Analog output module with a data width of
2 words. This module occupies the first 2
words in the output process image.
1 0008 00002
2 00003
3 00004
750-402
4 00005
4DI, 24 V:
2. Digital input module with a data width of 4
bits. These are added to the 2 bits of the 750-
400 and stored in the 8th word of the input
process image.
1 00004 0000
2 0001
3 0002
750-504
4 0003
4DO, 24 V:
1. Digital output module with a data width of 4
bits. Since the analog output module already
occupies the first 4 words of the output
process image, the 4 bits occupy the lowest-
value bits of the 4th word.
1 0000
750-454
2 0001
2AI, 4 – 20 mA:
1. Analog input module with a data width of 2
words. This module occupies the first 2 words
in the input process image.
0002 00002
0003 00003
750-650
1
RS232, C 9600/8/N/1:
The serial interface module is an analog input
and output module, which displays 2 words
apiece both in the input process image as well
as in the output process image.
1 0004
2 0005
3 0006
750-468
4 0007
4AI, 0 – 10 V S.E:
2. Analog input module with a data width of 4
words. Since the 750-454 and 750-650 analog
input and output modules already occupy the
first 4 words of the input process image, the 4
words of this I/O module are added behind the
others.
