Table 133: Description of the configuration scripts for "ETHERNET"
Parameter Status Call Output/Input Validity
ETHERNET
Transmission Mode Eth0
read
get_eth_config
eth0 autoneg
Query the status of the
Autonegotiation function:
on
off
config_interfaces
eth0 autoneg=on
Switch on Autonegotiation
function:
on
Autonegotiation
write
config_interfaces
interface=eth0
autoneg=off speed-
duplex=<value>
Switch Autonegotiation
function off:
off
Note:
The speed and duplex value
should be entered when
switching the
Autonegotiation off.
Entries for <value> are:
10-half
10-full
100-half
100-full
read
get_eth_config
eth0 speed
Display the ETHERNET
speed.
read
get_eth_config
eth0 duplex
Display of the duplex value.
Speed and
Duplex Settings
write
config_interfaces
interface=eth0
autoneg=off
speeed-duplex=<value>
Change the ETHERNET
speed and the Duplex
settings.
Entries for <value> are:
10-half
10-full
100-half
100-full
immediate
Transmission Mode Eth1
See "Transmission Mode Eth0". When calling, replace eth0 with eth1.
