WAGO-I/O-SYSTEM 750 CoDeSys 2.3 Runtime Environment 103
758-874/000-131 WAGO-I/O-IPC-C6
Manual
Version 1.0.0
Table 54: Addressing example
I/O Module Input Data Output Data Description
Type
C*
750-600
End module
The passive 750-600 End Module does not
transmit any data.
Analog input/output modules
Digital input/output modules
*
C: Number of the input/output
11.5 Installing the Programming System CoDeSys 2.3
(WAGO-I/O-PRO CAA)
The WAGO target files are installed during the installation of CoDeSys. These
contain all device-specific information for the WAGO 750/758 product series.
Proceed as described below to install the programming software CoDeSys 2.3 on
the I/O-IPC.
1. Insert the CD-ROM "WAGO-I/O-PRO CAA" into your computer drive.
2. To install the programming system, follow the instructions that appear on
your screen. A successful installation is indicated by a CoDeSys icon on
your desktop.
11.6 The First Program with CoDeSys 2.3
This section explains, through examples, the relevant steps required for the
creation of a CoDeSys project. It is intended as a set of quick start instructions and
does not address the full functional range of CoDeSys 2.3.
Further informations
Please see the manual "Handbook for PLC Programming with CoDeSys 2.3" on
the CD "WAGO-I/O-PRO CAA" (759-911) for a detailed description of the full
functional range.
11.6.1 Start the CoDeSys Programming System
Start CoDeSys by double clicking on the CoDeSys pictogram on your desktop or
through your operating system using your start menu. To do this, click on the
"Start" button and choose Program >
WAGO Software > CoDeSys for Automation Alliance > CoDeSys V2.3.
