15.2 Error Messages via I/O-LED
Pos: 51.12 /Serie 758 ( Funk, IPC und PFC)/Di agnose/Diagnose I/O-LED 758- 87x Einleitung @ 11\mod_13 15485565836_21.doc @ 78969 @ @ 1
This section describes I/O LED (38) in details.
Pos: 51.13 /Serie 758 ( Funk, IPC und PFC)/Di agnose/Diagnose I/O-LED 758- 87x allgemein @ 10\mod_13125 35406181_21.doc @ 76014 @ @ 1
It shows diagnostic messages of the I/O-IPC as a blink code. The number of blink
pulses indicates the error code and error argument. See the following sections.
If there are several error messages, the first message to occur chronologically
always blinks until it is corrected. Only then will any subsequent error message be
displayed.
Pos: 51.14 /Serie 758 ( Funk, IPC und PFC)/Di agnose/Diagnose I/O-LED 758- 87x FB - Bild @ 10\mod_1312535462 262_21.doc @ 76017 @ @ 1
RST
Stop
Run
U1
IDE/PWR
IO
ERR
STA
RDY
RUN
U2
A
B
C
D
Figure 108: Display of blink codes by the I/O-LED
