238 I/O Modules WAGO-I/O-SYSTEM 750
758-874/000-131 WAGO-I/O-IPC-C6
Manual
Version 1.0.0
750-404/000-005
The above Counter Modules have a total of 5 bytes of user data in both the Input
and Output Process Image (4 bytes of counter data and 1 byte of control/ status).
The two counter values are supplied as 16 bits. The following tables illustrate the
Input and Output Process Image, which has a total of 3 words mapped into each
image. Word alignment is applied.
Table 104: Counter Modules 750-404/000-005
Input Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 - S Status byte
1 D1 D0 Counter Value of Counter 1
2 D3 D2 Counter Value of Counter 2
Output Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 - C Control byte
1 D1 D0 Counter Setting Value of Counter 1
2 D3 D2 Counter Setting Value of Counter 2
750-638,
753-638
The above Counter Modules have a total of 6 bytes of user data in both the Input
and Output Process Image (4 bytes of counter data and 2 bytes of control/status).
The two counter values are supplied as 16 bits. The following tables illustrate the
Input and Output Process Image, which has a total of 4 words mapped into each
image. Word alignment is applied.
Table 105: Counter Modules 750-638, 753-638
Input Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 - S0 Status byte von Counter 1
1 D1 D0 Counter Value von Counter 1
2 - S1 Status byte von Counter 2
3 D3 D2 Counter Value von Counter 2
Output Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 - C0 Control byte von Counter 1
1 D1 D0 Counter Setting Value von Counter 1
2 - C1 Control byte von Counter 2
3 D3 D2 Counter Setting Value von Counter 2
