WAGO WAGO-I/O-IPC-C6 User Manual

WAGO-I/O-SYSTEM 750 I/O Modules 235
758-874/000-131 WAGO-I/O-IPC-C6
Manual
Version 1.0.0
18.2.3.3 4 Channel Analog Input Modules
750-453, -455, -457, -459, -460, -468, (and all variations),
753-453, -455, -457, -459
Table 100: 4 Channel Analog Input Modules
Input Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 D1 D0 Measured Value Channel 1
1 D3 D2 Measured Value Channel 2
2 D5 D4 Measured Value Channel 3
3 D7 D6 Measured Value Channel 4
