5.2 Interface for Electronic Power Supply (X4)
Feed the electronic power supply for the I/O-IPC and for the I/O modules
connected to the internal data bus in through this interface.
DANGER
Electric voltage!
Only operate the I/O-IPC with 24VDC PELV- (Protective Extra Low Voltage) or
SELV (Safety Extra Low Voltage) power sources. There is a danger of electric
shock if this precaution is not observed.
Pos: 34.5 /Dokumentatio n allgemein/Glieder ungselemente/---Seitenwechsel--- @ 3\mod_1221108045078_0.doc @ 21810 @ @ 1
Table 14: Interface for Electronic Power Supply: Pin Assignments
Connector Pin Description
1
V_IN (+)
2 GND (-)
1
2
3
3 Shield (optional)
