12.5 Diagnostics of the fieldbus coupler

This section requires a good knowledge of the CoDeSys programming tool. It

only describes the procedure to create diagnostics using the fieldbus master as an

example.

Configured slaves (e.g., a fieldbus coupler or a fieldbus controller) are a

prerequisite for diagnostics in fieldbus networks.

Pos: 46.13 /Serie 758 ( Funk, IPC und PFC)/Feldbusko mmunikation/CoDeSy s-Diagnose 758-87 x DMP Kanaldiagnose frei geben @ 10\mod_1313131671572_ 21.doc @ 76554 @ 3 @ 1

12.5.1 Releasing the Channel Diagnostics

You can release the diagnostics of the I/O modules to the slave by channel.

Proceed in the following manner:

1. Click on the "Resources" tab and then double click on "PLC Configuration."

2. Click on the name of the slave.

Figure 78: Release of channel diagnostics 1
