Table 123: KNX/EIB/TP1 Module 753-646
Input Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 - S0 not used Status byte
1 S1 OP
extended
Status byte
Opcode
2 D1 D0 Data byte 1 Data byte 0
3 D3 D2 Data byte 3 Data byte 2
4 D5 D4 Data byte 5 Data byte 4
5 D7 D6 Data byte 7 Data byte 6
6 D9 D8 Data byte 9 Data byte 8
7 D11 D10 Data byte 11 Data byte 10
8 D13 D12 Data byte 13 Data byte 12
9 D15 D14 Data byte 15 Data byte 14
10 D17 D16 Data byte 17 Data byte 16
11 D19 D18 Data byte 19 Data byte 18
Output Process Image
Byte Destination
Offset
High Byte Low Byte
Description
0 - C0 not used Control byte
1 C1 OP
extended
Control byte
Opcode
2 D1 D0 Data byte 1 Data byte 0
3 D3 D2 Data byte 3 Data byte 2
4 D5 D4 Data byte 5 Data byte 4
5 D7 D6 Data byte 7 Data byte 6
6 D9 D8 Data byte 9 Data byte 8
7 D11 D10 Data byte 11 Data byte 10
8 D13 D12 Data byte 13 Data byte 12
9 D15 D14 Data byte 15 Data byte 14
10 D17 D16 Data byte 17 Data byte 16
11 D19 D18 Data byte 19 Data byte 18
Pos: 60.18 /Serie 750 (W AGO-I/O-SYSTEM)/Pr ozessabbild Mapping/E THERNET - EtherNet/IP - MODBUS/TCP/PA ETHERNET - MODBUS/ TCP Teil 2 ASI- und Systemkle mmen (750-342, -830, - 842, -849) @ 5\mod_124654079 1017_21.doc @ 36540 @ 434 @ 1
18.2.5.17 AS-interface Master Module
750-655
The length of the process image of the AS-interface master module can be set to
fixed sizes of 12, 20, 24, 32, 40 or 48 bytes.
It consists of a control or status byte, a mailbox with a size of 0, 6, 10, 12 or 18
bytes and the AS-interface process data, which can range from 0 to 32 bytes.
The AS-interface master module has a total of 6 to maximally 24 words data in
both the Input and Output Process Image. Word alignment is applied.
The first Input and output word, which is assigned to an AS-interface master
module, contains the status / control byte and one empty byte.
Subsequently the mailbox data are mapped, when the mailbox is permanently
superimposed (Mode 1).
