ENGINE
M6040, M7040, WSM
1-S46
Governor Lever
1. Remove the spring pin (3).
2. Remove the speed control lever (2) and the return spring (1).
3. Remove the governor lever assembly (4) from the governor
housing.
4. Remove the start spring (6).
9Y1210143ENS0066US0
Stop Lever
1. Remove the spring pin (3).
2. Remove the stop lever (2) and the return spring (1).
3. Remove the stop lever shaft (4).
9Y1210143ENS0067US0
(1) Return Spring
(2) Speed Control Lever
(3) Spring Pin
(4) Governor Lever Assembly
(5) O-ring
(6) Start Spring
(1) Return Spring
(2) Stop Lever
(3) Spring Pin
(4) Stop Lever Shaft
(5) O-ring
KiSC issued 07, 2012 A
