ELECTRICAL SYSTEM
M6040, M7040, WSM
9-S6
LCD MONITOR
9Y1210143ELS0001US0
Symptom Probable Cause Solution
Reference
Page
Nothing is Displayed
in LCD
Battery discharged or defective (Battery voltage
is below 10 V)
Recharge or replace 9-S10
Slow blow fuse blown Replace 9-S11
Meter panel connector disconnect Connect 9-S25
Meter panel defective Replace 9-S25
Indication on LCD
Does Not Change
When Pushing the
Display Mode Switch
Display mode select switch defective Replace 9-S27
Wiring harness disconnected Repair –
Traveling Speed is
Not Indicating
Wiring harness disconnected Repair –
Traveling speed sensor defective Replace 9-S33
PTO Speed in Not
Indicating
Wiring harness disconnected Repair –
Engine tachometer sensor defective Replace 9-S33
KiSC issued 07, 2012 A
