YASKAWA GA700 Series

Docu ment No. E ZZ024048<1>
Pr epared in October, 2021
19 / 19
◼ o5-18：Analog Trigger Level
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-18
(1E85)
RUN
Analog Trigger
Level
0.0%
(-999.9% - +999.9%)
Sets the level to compare with the analog trigger target.
This parameter is only available when using an LCD
keypad.
◼ o5-19: Trigger Condition
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-19
(1E86)
RUN
Trigger Condition
0
(0 - 1)
Selects the condition with which to detect the trigger.
This parameter is only available when using an LCD
keypad.
0: Rising Edge
For a digital trigger, the trigger is detected when the digital trigger target switches from OFF
to ON. For an analog trigger, the trigger is detected when the analog trigger target changes
from less than the trigger level to greater than or equal to the trigger level.
1: Falling Edge
For a digital trigger, the trigger is detected when the digital trigger target switches from ON
to OFF. For an analog trigger, the trigger is detected when the analog trigger target
changes from more than the trigger level to less than or equal to the trigger level.
◼ o5-20: Pre-Trigger Setting
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-20
(1E87)
RUN
Pre-Trigger
Setting
90%
(0% - 100%)
Sets the percentage of data to save before the trigger is
detected for the short-term data log. This parameter is
only available when using an LCD keypad.
◼ o5-21: Trend Log Sampling Time Selection
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-21
(1E88)
RUN
Trend Log
Sampling Time
Selection
0
(0 - 4)
Selects the sampling cycle for the trend log to save data
before the trigger is detected. The trend log works
concurrently with the short-term data log. This
parameter is only available when using an LCD keypad.
0: Trend Log Disabled
The trend log is not saved.
1: 0.1 s (About 1 hour)
Saves a trend log with a sampling cycle of 0.1 s. A maximum of approximately one hour of
data is saved before the trigger is detected.
2: 1 s (About 10 hours)
Saves a trend log with a sampling cycle of 1 s. A maximum of approximately 10 hours of
data is saved before the trigger is detected.
3: 10 s (About 100 hours)
Saves a trend log with a sampling cycle of 10 s. A maximum of approximately 100 hours of
data is saved before the trigger is detected.
4: 60 s (About 600 hours)
Saves a trend log with a sampling cycle of 60 s. A maximum of approximately 600 hours of
data is saved before the trigger is detected.
V / f CL - V / f O LV C L V A OLV O L V / P M A O L V / P M C L V / P M E Z O L V
V / f CL - V / f O LV C L V A OLV O L V / P M A O L V / P M C L V / P M E Z O L V
V / f CL - V / f O LV C L V A OLV O L V / P M A O L V / P M C L V / P M E Z O L V
V / f CL - V / f O LV C L V A OLV O L V / P M A O L V / P M C L V / P M E Z O L V
