YASKAWA GA700 Series

4.6 Keypad Operation
150 YASKAWA SIEPC71061705H GA700 Series Technical Manual
Note:
The HOME screen must show U1-01 [Frequency Reference] or you must set the keypad as the Run command source (REMOTE) to use
this function.
■ Show the Main Menu
Push to show the main menu. Push [HOME] to go back to the HOME screen.
◆ Show the Monitor
This section shows how to show the standard monitors (Ux-xx).
1. Push [Home] to show the HOME screen.
Note:
• When the drive is in HOME Mode, the screen shows [Home] in the upper right-hand corner of the screen.
• If [Home] is not shown on , push (Back) to show [Home] on .
2. Push (Menu).
3. Push or to select [Monitors], then push .
4. Push or to select [Standard Monitor], then push .
5. Push or to select monitor group, then push .
6. Push or to change the monitor number to show the monitor item.
Note:
Push to go back to the previous page.
