1. Push [Home] to show the HOME screen.
Note:
• The keypad will [Home] in the top right corner when the HOME screen is active.
• If [Home] is not shown on , push [Back] to show [Home] on .
2. Push [Menu].
3. Push or to select [Monitors], then push .
4. Push or to select [Trend Plot], then push .
The screen will show the monitors as shown in this figure.
Note:
Push [Hold] to switch between Pause and Restart for the monitor display. The “Hold (ENTER)” message flashes while you pause
monitoring.
◆ Change Parameter Setting Values
This example shows how to change the setting value for C1-01 [Acceleration Time 1]. Do the steps in this
procedure to set parameters for the application.
1. Push (Home) to show the HOME screen.
Note:
• When the drive is in HOME Mode, the screen shows [Home] in the upper right-hand corner of the screen.
• If [Home] is not shown above the , push (Back).
2. Push (Menu).
