3.15 Protect the Drive during Failures
YASKAWA SIEPC71061705H GA700 Series Technical Manual 125
3.15 Protect the Drive during Failures
◆ Factory-Recommended Branch Circuit Protection for UL Listing
Use branch circuit protection to protect against short circuits and to maintain compliance with UL 508C. Yaskawa
recommends connecting semiconductor protection fuses on the input side for branch circuit protection. Refer to
Three-Phase 200 V Class on page 125 and Three-Phase 400 V Class on page 126 for more information about
recommended fuses.
WARNING! Electrical Shock Hazard. After the drive blows a fuse or trips an RCM/RCD, do not immediately energize the drive
or operate peripheral devices. Wait for the time specified on the warning label at a minimum and make sure that all indicators
are OFF. Then check the wiring and peripheral device ratings to find the cause of the problem. If you do not know the cause of
the problem, contact Yaskawa before you energize the drive or peripheral devices. If you do not fix the problem before you
operate the drive or peripheral devices, it can cause serious injury or death.
• 200 V Class
Use the fuses specified in this document to prepare the drive for use on a circuit that supplies not more than
100,000 RMS and not more than 240 Vac when there is a short circuit in the power supply.
• 400 V Class
Use the fuses specified in this document to prepare the drive for use on a circuit that supplies not more than
100,000 RMS and not more than 480 Vac when there is a short circuit in the power supply.
The built-in short circuit protection of the drive does not provide branch circuit protection. The user must provide
branch circuit protection as specified by the National Electric Code (NEC), the Canadian Electric Code, Part I
(CEC), and local codes.
■ Three-Phase 200 V Class
Table 3.19 Factory-Recommended Branch Circuit Protection: 200 V Class (ND)
Drive Model
Maximum Applicable Motor Output
kW (HP)
Input Current Rating
A
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
2004 0.75 (0.75) 4.8 FWH-45B
2006 1.1 (1.5) 6.7 FWH-45B
2010 2.2 (3) 12.7 FWH-45B
2012 3 (4) 17
FWH-50B
FWH-80B
*1
2018 3.7 (5) 20.7
FWH-80B
FWH-100B
*1
2021 5.5 (7.5) 30
FWH-80B
FWH-100B
*1
2030 7.5 (10) 40.3 FWH-125B
2042 11 (15) 52 FWH-150B
2056 15 (20) 78.4 FWH-200B
2070 18.5 (25) 96 FWH-225A
2082 22 (30) 114
FWH-225A
FWH-250A
*1
2110 30 (40) 111
FWH-225A
FWH-250A
*1
2138 37 (50) 136
FWH-275A
FWH-300A
*1
2169 45 (60) 164
FWH-275A
FWH-350A
*1
2211 55 (75) 200
FWH-325A
FWH-450A
*1
2257 75 (100) 271 FWH-600A
2313 90 (125) 324 FWH-800A
2360 110 (150) 394 FWH-1000B
2415 - - -
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
