11.10 H: Terminal Functions
546 YASKAWA SIEPC71061705H GA700 Series Technical Manual
◆ H6: Pulse Train Input/Output
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H6-01
(042C)
Terminal RP Pulse Train
Function
Sets the function for pulse train input terminal RP.
0 : Frequency Reference
1 : PID Feedback Value
2 : PID Setpoint Value
3 : Speed Feedback (V/F Control)
0
(0 - 3)
864
H6-02
(042D)
RUN
Terminal RP Frequency
Scaling
Sets the frequency of the pulse train input signal used when the item selected with H6-
01 [Terminal RP Pulse Train Function] is input at 100%.
1440 Hz
(100 - 32000 Hz)
865
H6-03
(042E)
RUN
Terminal RP Function
Gain
Sets the gain used when the function in H6-01 [Terminal RP Pulse Train Function] is
input to terminal RP.
100.0%
(0.0 - 1000.0%)
865
H6-04
(042F)
RUN
Terminal RP Function
Bias
Sets the bias used when the function in H6-01 [Terminal RP Pulse Train Function] is
input to terminal RP. Sets a value at the time when the pulse train is 0 Hz.
0.0%
(-100.0 - 100.0%)
865
H6-05
(0430)
RUN
Terminal RP Filter Time
Sets the time constant for the pulse train input primary delay filters.
0.10 s
(0.00 - 2.00 s)
865
H6-06
(0431)
RUN
Terminal MP Monitor
Selection
Sets a function for pulse train monitor output terminal MP. Sets the “x-xx” part of the
Ux-xx monitor.
102
(000, 031, 101, 102, 105,
116, 501, 502, 801 - 809,
821 - 825, 831 - 839, 851
- 855)
866
H6-07
(0432)
RUN
Terminal MP Frequency
Scaling
Sets the frequency of the pulse train output signal used when the monitor set with H6-
06 [Terminal MP Monitor Selection] is 100%.
1440 Hz
(0 - 32000 Hz)
866
H6-08
(043F)
Terminal RP Minimum
Frequency
Sets the minimum frequency of the pulse train signal that terminal RP can detect.
0.5 Hz
(0.1 - 1000.0 Hz)
866
H6-09
(156E)
Voltage Phase Sync MP
Selection
Set whether to output the pulse synchronized with drive output voltage phase from the
pulse train monitor output terminal MP. This parameter is only enabled when H6-06 =
102 [Terminal MP Monitor Selection = Output Frequency] and H6-07 = 0 [Terminal
MP Frequency Scaling = 0 Hz].
0 : Disabled
1 : Enabled
0
(0, 1)
867
◆ H7: Virtual MFIO selection
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H7-00
(116F)
Expert
Virtual MFIO selection
Sets the function to enable and disable the virtual I/O function. Set this parameter to 1
to operate the virtual I/O function.
0 : Disabled
1 : Enabled
0
(0, 1)
867
H7-01
(1185)
Expert
Virtual Multi-Function
Input 1
Sets the function that enters the virtual input set in H7-10 [Virtual Multi-Function
Output 1].
F
(1 - 19F)
868
H7-02
(1186)
Expert
Virtual Multi-Function
Input 2
Sets the function that enters the virtual input set in H7-12 [Virtual Multi-Function
Output 2].
F
(1 - 19F)
868
H7-03
(1187)
Expert
Virtual Multi-Function
Input 3
Sets the function that enters the virtual input set in H7-14 [Virtual Multi-Function
Output 3].
F
(1 - 19F)
868
H7-04
(1188)
Expert
Virtual Multi-Function
Input 4
Sets the function that enters the virtual input set in H7-16 [Virtual Multi-Function
Output 4].
F
(1 - 19F)
868
H7-10
(11A4)
Expert
Virtual Multi-Function
Output 1
Sets the function for virtual digital output 1.
F
(0 - 1A7)
868
