Parameter List
11
11.8 E: Motor Parameters
YASKAWA SIEPC71061705H GA700 Series Technical Manual 503
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E1-12
(030B)
Expert
Mid Point B Voltage
Sets a middle point voltage for the V/f pattern.
0.0 V
(200 V Class: 0.0 to
255.0 V, 400 V Class:
0.0 to 510.0 V)
746
E1-13
(030C)
Expert
Base Voltage
Sets the base voltage for the V/f pattern.
0.0 V
(200 V Class: 0.0 - 255.0
V,400 V Class: 0.0 -
510.0 V)
746
◆ E2: Motor Parameters
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E2-01
(030E)
Motor Rated Current
(FLA)
Sets the motor rated current in amps.
Determined by o2-04,
C6-01
(10% to 200% of the
drive rated current)
747
E2-02
(030F)
Motor Rated Slip
Sets motor rated slip.
Determined by o2-04,
C6-01
(0.000 - 20.000 Hz)
747
E2-03
(0310)
Motor No-Load Current
Sets the no-load current for the motor in amps when operating at the rated frequency
and the no-load voltage.
Determined by o2-04,
C6-01
(0 to E2-01)
747
E2-04
(0311)
Motor Pole Count
Sets the number of motor poles.
Note:
• When A1-02 = 0, 1, 3 [Control Method Selection = V/f, CL-V/f, CLV], the
maximum value is 120.
• When A1-02 = 2, 4 [OLV, AOLV], the maximum value is 48.
4
(2 - 120)
748
E2-05
(0312)
Motor Line-to-Line
Resistance
Sets the line-to-line resistance for the motor stator windings.
Determined by o2-04,
C6-01
(0.000 - 65.000 Ω)
748
E2-06
(0313)
Motor Leakage
Inductance
Sets the voltage drop from motor leakage inductance when the motor is operating at the
rated frequency and rated current. This value is a percentage of Motor Rated Voltage.
Determined by o2-04,
C6-01
(0.0 - 60.0%)
748
E2-07
(0314)
Motor Saturation
Coefficient 1
Sets the motor iron-core saturation coefficient at 50% of the magnetic flux.
0.50
(0.00 - 0.50)
748
E2-08
(0315)
Motor Saturation
Coefficient 2
Sets the motor iron-core saturation coefficient at 75% of the magnetic flux.
0.75
(E2-07 - 0.75)
748
E2-09
(0316)
Expert
Motor Mechanical Loss
Sets the mechanical loss of the motor. It is set as a percentage of E2-11 [Motor Rated
Power]. Usually it is not necessary to change this setting.
0.0%
(0.0 - 10.0%)
749
E2-10
(0317)
Motor Iron Loss
Sets the motor iron loss.
Determined by o2-04,
C6-01
(0 - 65535 W)
749
E2-11
(0318)
Motor Rated Power
Sets the motor rated output in the units from o1-58 [Motor Power Unit Selection].
Determined by o2-04,
C6-01
(0.00 - 650.00)
749
◆ E3: V/f Pattern for Motor 2
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E3-01
(0319)
Motor 2 Control Mode
Selection
Sets the control method for motor 2.
Note:
When you change this setting, the drive will set all parameters that are dependent on
this parameter to their default settings.
0 : V/f Control
1 : V/f Control with Encoder
2 : Open Loop Vector
3 : Closed Loop Vector
0
(0 - 3)
750
E3-04
(031A)
Motor 2 Maximum
Output Frequency
Set the maximum output frequency for the motor 2 V/f pattern.
Determined by E3-01
(40.0 - 590.0 Hz)
750
