YASKAWA GA700 Series

Startup Procedure and Test Run
4
4.6 Keypad Operation
YASKAWA SIEPC71061705H GA700 Series Technical Manual 175
9. Push or to select the hour or minute, then push or to change the value.
10. When you are done setting the time, push .
The procedure for setting the date and time is complete.
◆ Set Parameters Using the Setup Wizard
The Setup Wizard lets users follow simple messages on the keypad to set these basic parameters:
• Frequency Reference Source
• Input signal level
• Run command source
• Duty Rating
• Motor type
• Control Method Selection
• Maximum frequency
• Input/output settings
Note:
The Setup Wizard function will initialize all parameters before it sets the basic parameters.
1. Push [Home] to show the HOME screen.
Note:
• The keypad will [Home] in the top right corner when the HOME screen is active.
• If [Home] is not shown on , push [Back] to show [Home] on .
2. Push [Menu].
3. Push or to select [Initial Setup], then push .
