4.6 Keypad Operation
164 YASKAWA SIEPC71061705H GA700 Series Technical Manual
6. Push or to select a memory location, then push .
The keypad shows “End” when the backup procedure completes successfully.
◆ Write Backed-up Parameters to the Drive
You can back up parameters on the keypad and write them to different drives.
Note:
• Always stop the drive before you start to restore the parameter backups.
• While you verify parameters, the drive will not accept Run commands.
1. Push (Home) to show the HOME screen.
Note:
• When the drive is in HOME Mode, the screen shows [Home] in the upper right-hand corner of the screen.
• If the screen does not show [Home] for , push (Back), and then push to show [Home].
2. Push (Menu).
3. Push or to select [Parameter Backup/Restore], then push .
4. Push or to select the item to restore, then push .
5. Push or to select [Restore (keypad → drive)], then push .
