Parameter List
11
11.7 d: Reference Settings
YASKAWA SIEPC71061705H GA700 Series Technical Manual 501
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d6-03
(02A2)
Field Forcing Selection
Sets the field forcing function.
0 : Disabled
1 : Enabled
0
(0, 1)
737
d6-06
(02A5)
Field Forcing Limit
Sets the limit value for field forcing to increase the motor excitation current reference as
a percentage of E2-03 [Motor No-Load Current]. Usually it is not necessary to change
this setting.
400%
(100 - 400%)
737
◆ d7: Offset Frequency
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d7-01
(02B2)
RUN
Offset Frequency 1
Uses H1-xx = 44 [MFDI Function Select = Add Offset Frequency 1 (d7-01)] as a
percentage of the Maximum Output Frequency to add or subtract the set frequency to/
from the frequency reference.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(-100.0 - +100.0%)
738
d7-02
(02B3)
RUN
Offset Frequency 2
Uses H1-xx = 45 [MFDI Function Select = Add Offset Frequency 2 (d7-02)] as a
percentage of the Maximum Output Frequency to add or subtract the set frequency to/
from the frequency reference.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(-100.0 - +100.0%)
738
d7-03
(02B4)
RUN
Offset Frequency 3
Uses H1-xx = 46 [MFDI Function Select = Add Offset Frequency 3 (d7-03)] as a
percentage of the Maximum Output Frequency to add or subtract the set frequency to/
from the frequency reference.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(-100.0 - +100.0%)
738
