11.17 U: Monitors
YASKAWA SIEPC71061705H GA700 Series Technical Manual 579
No.
(Hex.)
Name Description MFAO Signal Level
U1-19
(0066)
MEMOBUS/Modbus Error
Code
Shows the contents of the MEMOBUS/Modbus communication error where 1 = error and 0 =
no error.
For example, U1-19 shows 00000001 when there is a CRC error.
bit0 : CRC Error
bit1 : Data Length Error
bit2 : Not used (normal value of 0).
bit3 : Parity Error
bit4 : Overrun Error
bit5 : Framing Error
bit6 : Timed Out
bit7 : Not used (normal value of 0).
No signal output available
U1-21
(0077)
AI-A3 Term V1 Level
Shows the analog reference of terminal V1 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to +10
V)
U1-22
(072A)
AI-A3 Term V2 Level
Shows the analog reference of terminal V2 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to +10
V)
U1-23
(072B)
AI-A3 Term V3 Level
Shows the analog reference of terminal V3 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to +10
V)
U1-24
(007D)
Input Pulse Monitor
Shows the frequency to pulse train input terminal RP.
Unit: 1 Hz
Determined by H6-02
U1-25
(004D)
SoftwareNumber Flash
Shows the FLASH ID.
No signal output available
U1-26
(005B)
SoftwareNumber ROM
Shows the ROM ID.
No signal output available
U1-50
(1199)
Expert
Virtual Analog Input
Shows the virtual analog input value.
Determined by H7-40
U1-91
(154E)
Expert
Output Voltage
Shows the drive internal output voltage reference.
Unit: 0.1 V
200 V Class: 10 V = 200
Vrms
400 V Class: 10 V = 400
Vrms
U2: Fault Trace
No.
(Hex.)
Name Description MFAO Signal Level
U2-01
(0080)
Current Fault
Shows the fault that the drive has when viewing the monitor.
No signal output available
U2-02
(0081)
Previous Fault
Shows the fault that occurred most recently.
No signal output available
U2-03
(0082)
Freq Reference@Fault
Shows the frequency reference at the fault that occurred most recently.
Use U1-01 [Frequency Reference] to monitor the frequency reference value.
Unit: 0.01 Hz
No signal output available
U2-04
(0083)
Output Freq @ Fault
Shows the output frequency at the fault that occurred most recently.
Use U1-02 [Output Frequency] to monitor the actual output frequency.
Unit: 0.01 Hz
No signal output available
U2-05
(0084)
Output Current@Fault
Shows the output current at the fault that occurred most recently.
Use U1-03 [Output Current] to monitor the output current. The keypad shows the value of U1-03
in amperes (A).
When you use MEMOBUS/Modbus communications to show the monitor, the current is 8192 =
drive rated current (A). Use the formula: Numerals being displayed / 8192 × drive rated current
(A) to use the MEMOBUS/Modbus communication current value shown in the monitor.
Unit: When the drive model changes, the display units for this parameter also change.
0.01 A: 2004 - 2042, 4002 - 4023
0.1 A: 2056 - 2415, 4031 - 4675
No signal output available
