YASKAWA GA700 Series

Standards Compliance
5
5.3 UL Standards
YASKAWA SIEPC71061705H GA700 Series Technical Manual 259
Drive Model
Fuse
Manufacturer: Bussmann
Model Qty
2211
FWH-450A
FWH-600A
*1
2
2257
FWH-600A
FWH-700A
*1
2
Drive Model
Fuse
Manufacturer: Bussmann
Model Qty
2313
FWH-800A
FWH-1000B
*1
2
2360 FWH-1000B 2
2415 FWH-1000B 2
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads of approximately 150%.
Table 5.22 Recommended Fuse (Three-Phase 400 V Class)
Drive Model
Fuse
Manufacturer: Bussmann
Model Qty
4002 FWH-50B 2
4004 FWH-50B 2
4005 FWH-50B 2
4007 FWH-60B 2
4009 FWH-60B 2
4012 FWH-60B 2
4018 FWH-80B 2
4023 FWH-90B 2
4031 FWH-150B 2
4038 FWH-200B 2
4044 FWH-200B 2
4060 FWH-225A 2
4075 FWH-250A 2
4089 FWH-275A 2
4103 FWH-275A 2
Drive Model
Fuse
Manufacturer: Bussmann
Model Qty
4140
FWH-300A
FWH-325A
*1
2
4168
FWH-400A
FWH-450A
*1
2
4208
FWH-500A
FWH-600A
*1
2
4250
FWH-600A
FWH-700A
*1
2
4296
FWH-700A
FWH-800A
*1
2
4371
FWH-800A
FWH-1000B
*1
2
4389
FWH-1000B
FWH-1200B
*1
2
4453
FWH-1200B
FWH-1400A
*1
2
4568
FWH-1200B
FWH-1600A
*1
2
4675 FWH-1600A 2
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads of approximately 150%.
◆ Low Voltage Wiring for Control Circuit Terminals
You must provide low voltage wiring as specified by the National Electric Code (NEC), the Canadian Electric
Code, Part I (CEC), and local codes. Yaskawa recommends the NEC class 1 circuit conductor. Use the UL
approved class 2 power supply for external power supply.
Table 5.23 Control Circuit Terminal Power Supplies
Input/Output Terminals Power Supply Specifications
Digital input S1 to S8, SN, SC, SP
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external
power supply.
Analog input A1 to A3, AC, +V, -V
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external
power supply.
Analog output FM, AM, AC Uses the LVLC power supply in the drive.
Pulse train output MP, AC
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external
power supply.
Pulse train input RP, AC
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external
power supply.
Safe disable input H1, H2, HC
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external
power supply.
