11.8 E: Motor Parameters
502 YASKAWA SIEPC71061705H GA700 Series Technical Manual
11.8 E: Motor Parameters
◆ E1: V/f Pattern for Motor 1
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E1-01
(0300)
Input AC Supply Voltage
Sets the drive input voltage.
NOTICE: Damage to Equipment. Set E1-01 [Input AC Supply
Voltage] to align with the drive input voltage (not motor
voltage). If this parameter is incorrect, the protective functions
of the drive will not operate correctly and it can cause damage
to the drive.
200 V Class: 230 V,
400 V Class: 400 V
(200 V Class: 155 to 255
V, 400 V Class: 310 to
510 V)
740
E1-03
(0302)
V/f Pattern Selection
Sets the V/f pattern for the drive and motor. You can use one of the preset patterns or
you can make a custom pattern.
0 : Const Trq, 50Hz base, 50Hz max
1 : Const Trq, 60Hz base, 60Hz max
2 : Const Trq, 50Hz base, 60Hz max
3 : Const Trq, 60Hz base, 72Hz max
4 : VT, 50Hz, 65% Vmid reduction
5 : VT, 50Hz, 50% Vmid reduction
6 : VT, 60 Hz, 65% Vmid reduction
7 : VT, 60Hz, 50% Vmid reduction
8 : High Trq, 50Hz, 25% Vmin boost
9 : High Trq, 50Hz, 65% Vmin boost
A : High Trq, 60Hz, 25% Vmin boost
B : High Trq, 60Hz, 65% Vmin boost
C : High Freq, 60Hz base, 90Hz max
D : High Freq, 60Hz base, 120Hz max
E : High Freq, 60Hz base, 180Hz max
F : Custom
Note:
• When A1-02 = 2 [Control Method Selection = OLV], settings 0 to E are not
available.
• Set the correct V/f pattern for the application and operation area. An incorrect V/f
pattern can decrease motor torque and increase current from overexcitation.
F
(Determined by A1-02)
740
E1-04
(0303)
Maximum Output
Frequency
Sets the maximum output frequency for the V/f pattern.
Determined by A1-02
and E5-01
(Determined by A1-02
and E5-01)
745
E1-05
(0304)
Maximum Output
Voltage
Sets the maximum output voltage for the V/f pattern.
200.0
(200 V Class: 0.0 - 255.0
V, 400 V Class: 0.0 -
510.0 V)
745
E1-06
(0305)
Base Frequency
Sets the base frequency for the V/f pattern.
Determined by A1-02
and E5-01
(0.0 - E1-04)
745
E1-07
(0306)
Mid Point A Frequency
Sets a middle output frequency for the V/f pattern.
Determined by A1-02
(0.0 - E1-04)
745
E1-08
(0307)
Mid Point AVoltage
Sets a middle output voltage for the V/f pattern.
Determined by A1-02，
C6-01 and o2-04
(200 V Class: 0.0 - 255.0
V,
400 V Class: 0.0 - 510.0
V)
746
E1-09
(0308)
Minimum Output
Frequency
Sets the minimum output frequency for the V/f pattern.
Determined by A1-02
and E5-01
(Determined by A1-02,
E1-04, and E5-01)
746
E1-10
(0309)
Minimum Output
Voltage
Sets the minimum output voltage for the V/f pattern.
Determined by A1-02
(200 V Class: 0.0 to
255.0 V, 400 V Class:
0.0 to 510.0 V)
746
E1-11
(030A)
Expert
Mid Point B Frequency
Sets a middle output frequency for the V/f pattern.
0.0 Hz
(0.0 - E1-04)
746
