Parameter List
11
11.5 b: Application
YASKAWA SIEPC71061705H GA700 Series Technical Manual 485
No.
(Hex.)
Name Description
Default
(Range)
Ref.
b3-56
(3126)
InverseRotationSearch
WaitTime
Sets the wait time until the drive starts inverse rotation search after it completes forward
search when you do inverse rotation search during Current Detection Speed Search.
Determined by o2-04
(0.1 - 5.0 s)
666
b3-61
(1B96)
Expert
Init Magnet Pole
Estimation Gain
Sets the responsiveness for initial motor magnetic pole calculation when A1-02 = 6
[Control Method Selection = AOLV/PM]. Set b3-61 > 0.0 for an ordinary IPM motor.
When you use High Frequency Injection Auto-Tuning, the drive will automatically set
this value.
Note:
• Set n8-35 = 1 [Initial Pole Calculation Method = High Frequency Injection] to
enable this parameter.
• When A1-02= 6 [AOLV/PM] and you do High Frequency Injection Auto-Tuning,
the drive automatically sets this parameter .
• Set n8-41 [HFI P Gain] to adjust the responsiveness for initial motor magnetic
pole calculation when A1-02 = 5, 7 [OLV/PM, CLV/PM].
5.0
(-20.0 - +20.0)
666
◆ b4: Timer Function
No.
(Hex.)
Name Description
Default
(Range)
Ref.
b4-01
(01A3)
Timer Function ON-
Delay Time
Sets the ON-delay time for the timer input.
0.0 s
(0.0 - 3000.0 s)
667
b4-02
(01A4)
Timer Function OFF-
Delay Time
Sets the OFF-delay time for the timer input.
0.0 s
(0.0 - 3000.0 s)
667
b4-03
(0B30)
Expert
Terminal M1-M2 ON-
Delay Time
Sets the delay time to activate the contact after the function set in H2-01 activates.
0 ms
(0 - 65000 ms)
667
b4-04
(0B31)
Expert
Terminal M1-M2 OFF-
Delay Time
Sets the delay time to deactivate the contact after the function set in H2-01 deactivates.
0 ms
(0 - 65000 ms)
667
b4-05
(0B32)
Expert
Terminal M3-M4 ON-
Delay Time
Sets the delay time to activate the contact after the function set in H2-02 activates.
0 ms
(0 - 65000 ms)
667
b4-06
(0B33)
Expert
Terminal M3-M4 OFF-
Delay Time
Sets the delay time to deactivate the contact after the function set in H2-02 deactivates.
0 ms
(0 - 65000 ms)
668
b4-07
(0B34)
Expert
Terminal M5-M6 ON-
Delay Time
Sets the delay time to activate the contact after the function set in H2-03 activates.
0 ms
(0 - 65000 ms)
668
b4-08
(0B35)
Expert
Terminal M5-M6 OFF-
Delay Time
Sets the delay time to deactivate the contact after the function set in H2-03 deactivates.
0 ms
(0 - 65000 ms)
668
◆ b5: PID control
No.
(Hex.)
Name Description
Default
(Range)
Ref.
b5-01
(01A5)
PID Mode Setting
Sets the type of PID control.
0 : Disabled
1 : Standard
2 : Standard (D on feedback)
3 : Fref + PID Trim
4 : Fref + PID Trim (D on feedback)
5 : Same as 7series & prior, b5-01=1
6 : Same as 7series & prior, b5-01=2
7 : Same as 7series & prior, b5-01=3
8 : Same as 7series & prior, b5-01=4
Note:
Use settings 5 to 8 when the drive is a replacement for a previous generation drive.
0
(0 - 8)
673
b5-02
(01A6)
RUN
Proportional Gain (P)
Sets the proportional gain (P) that is applied to PID input.
1.00
(0.00 - 25.00)
674
