o5-10: Log Monitor D ata 8
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-10
(155A)
RUN
Log Monitor Data
8
000
(000,101 - 999)
Sets the data log monitor. This parameter is only
available when using an LCD keypad.
Note: Set the
U monitor
number you will log.
For example, to display
U1-01 [Frequency Reference]
, set
o5-10
=
101
. When it is
not necessary to set a data log monitor, set this parameter to
000
.
o5-11: Log Monitor D ata 9
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-11
(155B)
RUN
Log Monitor Data
9
000
(000,101 - 999)
Sets the data log monitor. This parameter is only
available when using an LCD keypad.
Note: Set the
U monitor
number you will log.
For example, to display
U1-01 [Frequency Reference]
, set
o5-11
=
101
. When it is
not necessary to set a data log monitor, set this parameter to
000
.
o5-12: Log Monitor D ata 10
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-12
(155C)
RUN
Log Monitor Data
10
000
(000,101 - 999)
Sets the data log monitor. This parameter is only
available when using an LCD keypad.
Note: Set the
U monitor
number you will log.
For example, to display
U1-01 [Frequency Reference]
, set
o5-12
=
101
. When it is
not necessary to set a data log monitor, set this parameter to
000
.
o5-15: Trigger Type Selection
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-15
(1E82)
RUN
Trigger Type
Selection
0
(0 - 1)
Selects the type of trigger for the short-term data log.
This parameter is only available when using an LCD
keypad.
0: Digital Trigger
A digital signal inside the drive will act as the trigger.
1: Analog Trigger
An analog signal inside the drive will act as the trigger.
Note: There are no detection width and detection time settings for the analog trigger in the
data log function. If variations in the analog signal become a problem, select the
digital trigger and use
o5-16 = 66/67 [Digital Trigger Object = Comparator 1/2]
. Set
the conditions for the comparator function with
H2-20
to
H2-32
.
o5-16: Digital Trigger Object
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-16
(1E83)
RUN
Digital Trigger
Object
E
(0 - FF)
Selects the function to set for the digital trigger target
from the setting values for multi-function digital outputs.
This parameter is only available when using an LCD
keypad.
o5-17: Analog Trigger Object
No.
( Hex.)
Name
De scription
De fault
( Range)
o5-17
(1E84)
RUN
Analog Trigger
Object
102
(0 999)
Selects the monitor
(Ux-xx)
to set for the analog trigger
target. This parameter is only available when using an
LCD keypad.
V / f
CL - V / f
O LV C L V A OLV
O L V / P M A O L V / P M C L V / P M
E Z O L V
V / f
CL - V / f
O LV C L V A OLV
O L V / P M A O L V / P M C L V / P M
E Z O L V
V / f
CL - V / f
O LV C L V A OLV
O L V / P M A O L V / P M C L V / P M
E Z O L V
V / f
CL - V / f
O LV C L V A OLV
O L V / P M A O L V / P M C L V / P M
E Z O L V
V / f
CL - V / f
O LV C L V A OLV
O L V / P M A O L V / P M C L V / P M
E Z O L V
V / f
CL - V / f
O LV C L V A OLV
O L V / P M A O L V / P M C L V / P M
E Z O L V
