2.10 Installation Methods
YASKAWA SIEPC71061705H GA700 Series Technical Manual 55
2.10 Installation Methods
The drive installation methods include standard installation and external heatsink installation.
◆ Standard Installation
Refer to Drive Exterior and Mounting Dimensions on page 446 for more information about external dimensions
and installation methods.
◆ External Heatsink
Refer to Table 2.14, Table 2.15, and Table 2.16 for the panel cut-out dimensions for external heatsink installations.
An attachment is necessary to install drive models smaller than 2082 (200 V class) and 4060 (400 V class) with
the heatsink outside of the panel.
Note:
• The exterior mounting dimensions and installation dimensions for a standard installation are different than the dimensions for an
external heatsink installation.
• The shaded parts of the panel cut-out dimensions are the gasket dimensions. Make sure that the gasket is not smaller than the specified
dimension.
Table 2.13 External Heatsink Attachment
Drive Model Model
2004 - 2042
4002 - 4023
900-193-209-001
2056
4031, 4038
900-193-209-002
2070, 2082
4044, 4060
900-193-209-003
2110 - 2415
4075 - 4675
-
