YASKAWA GA700 Series

Startup Procedure and Test Run
4
4.6 Keypad Operation
YASKAWA SIEPC71061705H GA700 Series Technical Manual 151
◆ Set Custom Monitors
You can select and register a maximum of 12 monitoring items to regularly show on the keypad.
This procedure shows how to set the motor speed to [Custom Monitor 1].
1. Push (Home) to show the HOME screen.
Note:
• The keypad will show [Home] in the top right corner when the HOME screen is active.
• If the keypad does not show [Home] on , push (Back) to show [Home] on .
2. Push (Menu).
3. Push or to select [Monitors], then push .
4. Push or to select [Custom Monitor], then push (Setup).
5. Push or to select [Custom Monitor 1], then push .
6. Push or to select the monitor number to register, then push .
Set the x-xx part of monitor Ux-xx. For example, to show monitor U1-05, set it to “105” as shown in this
figure.
