YASKAWA GA700 Series

Parameter List
11
11.21 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA SIEPC71061705H GA700 Series Technical Manual 609
◆ Three-Phase 400 V Class
No.
*1
Name Unit Default
- Drive Model - 4002 4004 4005 4007
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 92 93 94 95
E2-11
(E4-11)
Motor Rated
Power
kW 0.4 0.75 1.1 1.5 1.5 2.2 2.2 3.0
b3-04
V/f Gain
during Speed
Search
% 100 100 100 100 100 100 100 100
b3-06
Speed
Estimation
Current Level
1
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed
Estimation
ACR P Gain
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Direction
Determination
Level
- 1000 1000 1000 1000 1000 1000 1000 1000
b8-03
Energy Saving
Filter Time
s 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04
Energy Saving
Coefficient
Value
- 576.4 447.4 447.4 338.8 338.8 313.6 313.6 265.7
C5-17
(C5-37)
Motor Inertia kgm
2
0.0015 0.0028 0.0028 0.0068 0.0068 0.0088 0.0088 0.0158
C6-02
Carrier
Frequency
Selection
- 1 7 1 7 1 7 1 7
E2-01
(E4-01)
Motor Rated
Current (FLA)
A 1 1.6 1.6 3.1 3.1 4.2 4.2 5.7
E2-02
(E4-02)
Motor Rated
Slip
Hz 2.9 2.6 2.6 2.5 2.5 3 3 2.7
E2-03
(E4-03)
Motor No-
Load Current
A 0.6 0.8 0.8 1.4 1.4 1.5 1.5 1.9
E2-05
(E4-05)
Motor Line-
to-Line
Resistance
Ω 38.198 22.459 22.459 10.1 10.1 6.495 6.495 4.360
E2-06
(E4-06)
Motor
Leakage
Inductance
% 18.2 14.3 14.3 18.3 18.3 18.7 18.7 19
E2-10
(E4-10)
Motor Iron
Loss
W 14 26 26 53 53 77 77 105
E5-01
PM Motor
Code
Selection
- 1232 1232 1233 1233 1235 1235 1236 1236
L2-02
Power Loss
Ride Through
Time
s 0.1 0.1 0.2 0.2 0.3 0.3 0.5 0.5
L2-03
Minimum
Baseblock
Time
s 0.2 0.3 0.3 0.4 0.4 0.5 0.5 0.5
L2-04
Powerloss V/f
Recovery
Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 380 380 380 380 380 380 380 380
L3-24
Motor Accel
Time @ Rated
Torque
s 0.178 0.142 0.142 0.166 0.166 0.145 0.145 0.145
L8-02
Overheat
Alarm Level
°C 100 100 105 105 112 112 100 100
