11.4 A: Initialization Parameters
478 YASKAWA SIEPC71061705H GA700 Series Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
A1-07
(0128)
DriveWorksEZ Function
Selection
Sets the drive to operate with DriveWorksEZ.
0 : DWEZ Disabled
1 : DWEZ Enabled
2 : Enabled/Disabled wDigital Input
0
(0 - 2)
639
A1-11
(111D)
Expert
Firmware Update Lock
Protects the drive firmware. When you enable the protection, you cannot update the
drive firmware.
0 : Disabled
1 : Enabled
0
(0, 1)
639
A1-12
(1564)
Bluetooth ID
Sets the password necessary to use Bluetooth to control the drive with a smartphone or
tablet.
-
(0000 - 9999)
640
◆ A2: User Parameters
No.
(Hex.)
Name Description
Default
(Range)
Ref.
A2-01
(0106)
User Parameter 1
Sets the parameter number to be shown for number 1 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
A1-02
(Determined by A1-06)
640
A2-02
(0107)
User Parameter 2
Sets the parameter number to be shown for number 2 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
b1-01
(Determined by A1-06)
640
A2-03
(0108)
User Parameter 3
Sets the parameter number to be shown for number 3 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
b1-02
(Determined by A1-06)
640
A2-04
(0109)
User Parameter 4
Sets the parameter number to be shown for number 4 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
b1-03
(Determined by A1-06)
640
A2-05
(010A)
User Parameter 5
Sets the parameter number to be shown for number 5 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
C1-01
(Determined by A1-06)
640
A2-06
(010B)
User Parameter 6
Sets the parameter number to be shown for number 6 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
C1-02
(Determined by A1-06)
640
A2-07
(010C)
User Parameter 7
Sets the parameter number to be shown for number 7 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
C6-01
(Determined by A1-06)
640
A2-08
(010D)
User Parameter 8
Sets the parameter number to be shown for number 8 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
C6-02
(Determined by A1-06)
640
A2-09
(010E)
User Parameter 9
Sets the parameter number to be shown for number 9 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-01
(Determined by A1-06)
640
A2-10
(010F)
User Parameter 10
Sets the parameter number to be shown for number 10 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-02
(Determined by A1-06)
640
A2-11
(0110)
User Parameter 11
Sets the parameter number to be shown for number 11 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-03
(Determined by A1-06)
640
A2-12
(0111)
User Parameter 12
Sets the parameter number to be shown for number 12 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-04
(Determined by A1-06)
640
A2-13
(0112)
User Parameter 13
Sets the parameter number to be shown for number 13 of the [User Custom Parameters]
under the main menu. You can select a maximum of 32 parameters for the drive and set
them to parameters A2-01 to A2-32.
d1-17
(Determined by A1-06)
640
