Parameter List
11
11.12 n: Special Adjustment
YASKAWA SIEPC71061705H GA700 Series Technical Manual 561
◆ n6: Online Tuning
No.
(Hex.)
Name Description
Default
(Range)
Ref.
n6-01
(0570)
Online Tuning Selection
Sets the type of motor data that Online Tuning uses for OLV control.
0 : Disabled
1 : Line-to-Line Resistance Tuning
2 : Voltage Correction Tuning
0
(0 - 2)
930
n6-05
(05C7)
Expert
Online Tuning Gain
Sets the compensation gain when n6-01 = 2 [Online Tuning Selection = Voltage
Correction Tuning]. Usually it is not necessary to change this parameter.
1.0
(0.1 - 50.0)
931
n6-11
(1B56)
Expert
Online Resistance
Tuning
Sets the responsiveness for online resistor tuning. Set this parameter to approximately
1.000 to enable the function. The function is disabled when the value is 0.000.
0.000
(0.000 - 1.000)
931
◆ n7: EZ Drive
No.
(Hex.)
Name Description
Default
(Range)
Ref.
n7-01
(3111)
Expert
Damping Gain for Low
Frequency
Sets the oscillation suppression gain for the low speed range.
1.0
(0.1 - 10.0)
931
n7-05
(3115)
Expert
Response Gain for Load
Changes
Sets the response gain related to changes in the load.
100
(10 - 1000)
931
n7-07
(3117)
Expert
Speed Calculation Gain1
Sets the speed calculation gain during usual operation. Usually it is not necessary to
change this setting.
15.0
(1.0 - 50.0)
931
n7-08
(3118)
Expert
Speed Calculation Gain2
Sets the speed calculation gain during a speed search.
25.0
(1.0 - 50.0)
931
n7-10
(311A)
Expert
Pull-in Current
Switching Speed
Sets the speed range to operate with the pull-in current command. Drive rated frequency
= 100% value. If there is a large quantity of oscillation when you operate in the low
speed range, increase the setting value.
10.0%
(0.0 - 100.0%)
932
n7-11
(311B)
Expert
Drv Mode Switch
Hysteresis Band
Usually it is not necessary to change this setting. Sets the hysteresis level for Switching
Speed set in n7-10 [Pull-in Current Switching Speed].
When the speed is lower than n7-10 + n7-11 during acceleration, the drive enables pull-
in current.
Note:
• When the drive accelerates, it enables these settings:
–Motor speed ≤ n7-10 + n7-11: n8-51 [Pull-in Current @ Acceleration]
–Motor speed > n7-10 + n7-11: b8-01 [Energy Saving Control Selection]
• If there is a large quantity of oscillation when you operate in the low speed range,
increase the setting value.
• When it is most important to save energy in the low speed range, decrease the
setting value.
5.0%
(1.0 - 20.0%)
932
n7-13
(311D)
Expert
Driving Method
Switching Time
Sets a time to enable the pull-in current commands.
If there is a large quantity of oscillation at speeds around n7-10 [Pull-in Current
Switching Speed], decrease the setting in 20 ms decrements.
100 ms
(0 - 1000 ms)
932
n7-17
(3122)
Resistance
TemperatureCorrection
Sets the function to adjust for changes in the motor resistance value caused by changes
in the temperature.
0 : Invalid
1 : Valid (Only 1 time)
2 : Valid (Every time)
1
(0 to 2)
932
