YASKAWA GA700 Series

Mechanical Installation
2
2.5 Drive Watt Loss
YASKAWA SIEPC71061705H GA700 Series Technical Manual 39
2.5 Drive Watt Loss
◆ 200 V Class
Table 2.1 Drive Watt Loss (Heavy Duty)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2004
3.2 8 35 18 53
2006
5 8 37 26 63
2010
8 8 44 43 87
2012
11 8 50 61 111
2018
14 8 47 82 129
2021
17.5 8 56 105 161
2030
25 8 74 174 248
2042
33 8 88 183 271
2056
47 8 112 267 379
2070
60 8 145 373 518
2082
75 8 179 478 657
2110
88 8 155 563 718
2138
115 8 212 680 892
2169
145 5 275 820 1095
2211
180 5 314 991 1305
2257
215 5 398 1252 1650
2313
283 5 502 1643 2145
2360
346 5 582 1978 2560
2415
415 5 644 2359 3003
Table 2.2 Drive Watt Loss (Normal Duty)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2004
3.5 2 35 16 51
2006
6 2 38 25 63
2010
9.6 2 49 46 95
2012
12.2 2 56 62 118
2018
17.5 2 53 88 141
2021
21 2 75 125 200
2030
30 2 95 206 301
2042
42 2 129 227 356
2056
56 2 149 302 451
2070
70 2 177 403 580
2082
82 2 202 467 669
2110
110 2 192 631 823
2138
138 2 269 814 1083
2169
169 2 338 941 1279
2211
211 2 384 1131 1515
2257
257 2 519 1534 2053
2313
313 2 579 1794 2373
2360
360 2 655 2071 2726
2415 - - - - -
