YASKAWA GA700 Series

Specifications
10
10.4 Model-Specific Specifications (400 V Class)
YASKAWA SIEPC71061705H GA700 Series Technical Manual 431
10.4 Model-Specific Specifications (400 V Class)
Table 10.5 Rating (400 V Class)
Model
Input
Voltage
Duty
Rating
4002 4004 4005 4007 4009 4012 4018 4023
Maximum Applicable
Motor Output (kW)
< 460 V
*1
HD1 0.55
1.1 1.5 2.2 3.0 4.0 5.5 7.5
ND1 0.75
1.5 2.2 3.0 4.0 5.5 7.5 11
≥ 460 V
*2
HD2 0.55
0.75 1.5 2.2 3 3.7 5.5 7.5
ND2 0.75
1.5 2.2 3 3.7 5.5 7.5 11
Maximum Applicable
Motor Output (HP)
< 460 V
*1
HD1 3/4
1.5 2 3 4 5 7.5 10
ND1 1
2 3 4 5 7.5 10 15
≥ 460 V
*2
HD2 3/4
1 2 3 4 5 7.5 10
ND2 1
2 3 4 5 7.5 10 15
Input
Rated Input
Current (A)
< 460 V
HD1 (AC) 1.9
3.5 4.7 6.7 8.9 11.7 15.8 21.2
HD1 (DC) 2.3
4.3 5.8 8.2 10.9 14.3 19.4 26.0
ND1 (AC) 2.5
4.7 6.7 8.9 11.7 15.8 21.2 30.6
ND1 (DC) 3.1
5.8 8.2 10.9 14.3 19.4 26.0 37.5
≥ 460 V
HD2 (AC) 1.6
2.1 3.9 5.5 7.4 9.0 13.1 17.5
HD2 (DC) 1.9
2.5 4.8 6.8 9.0 11.0 16.0 21.5
ND2 (AC) 2.1
3.9 5.5 7.4 9.0 13.1 17.5 25.3
ND2 (DC) 2.5
4.8 6.8 9.0 11.0 16.0 21.5 31.0
Output
Rated Output
Capacity
(kVA)
< 460 V
*3
HD1 1.2
2.2 3.2 3.6 4.7 6.1 10 12
ND1 1.4
2.7 3.6 4.7 5.9 7.8 12 15
≥ 460 V
*4
HD2 1.3
1.7 2.7 3.8 5.5 6.1 8.8 11
ND2 1.7
2.7 3.8 5.5 6.1 8.8 11 17
Rated Output
Current (A)
< 460 V
HD1 1.8
3.4 4.8 5.5 7.2 9.2 14.8 18
ND1 2.1
4.1 5.4 7.1 8.9 11.9 17.5 23.4
≥ 460 V
HD2 1.6
2.1 3.4 4.8 6.9 7.6 11 14
ND2 2.1
3.4 4.8 6.9 7.6 11 14 21
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds The permitted frequency of overload is one time each 10
minutes.
• ND: 110% of the rated output current for 60 seconds The permitted frequency of overload is one time each 10
minutes.
Note:
Derating can be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 380 V to 480 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• AOLVand EZOLV: 120 Hz
• CL-V/f, CLV, AOLV/PM, and CLV/PM: 400 Hz
• V/f, OLV, OLV/PM: 590 Hz
Measures for
Harmonics
DC reactor External options
Braking
Device
Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3, C3
Factory option
• Models 4xxxB: There is a category C3 EMC filter in the drive.
