YASKAWA GA700 Series

10.4 Model-Specific Specifications (400 V Class)
432 YASKAWA SIEPC71061705H GA700 Series Technical Manual
Model
Input
Voltage
Duty
Rating
4002 4004 4005 4007 4009 4012 4018 4023
Power
Supply
Rated Voltage, Rated Frequency
• Three-phase AC power supply 380 V to 480 Vat 50/60 Hz
• DC power supply 513 V to 679 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
< 460 V
HD1
1.5 2.8 3.7 5.3 7.1 9.3 13 17
ND1
2.0 3.7 5.3 7.1 9.3 13 17 24
≥ 460 V
HD2
1.3 1.7 3.2 4.6 6.2 7.5 11 15
ND2
1.7 3.2 4.6 6.2 7.5 11 15 21
*1 The maximum applicable motor output complies with 380 V motor ratings as specified in Annex G of IEC 60947-4-1. The rated
output current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 460 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*3 The rated output capacity is calculated with a rated output voltage of 380 V.
*4 The rated output capacity is calculated with a rated output voltage of 460 V.
Table 10.6 Rating (400 V Class)
Model
Input
Voltage
Duty Rating 4031 4038 4044 4060 4075 4089 4103
Maximum Applicable Motor
Output (kW)
< 460 V
*1
HD1
11 15 18.5 22 30 37 45
ND1
15 18.5 22 30 37 45 55
≥ 460 V
*2
HD2
11 15 18.5 22 30 37 45
ND2
15 18.5 22 30 37 45 55
Maximum Applicable Motor
Output (HP)
< 460 V
*1
HD1
15 20 25 30 40 50 60
ND1
20 25 30 40 50 60 75
≥ 460 V
*2
HD2
15 20 25 30 40 50 60
ND2
20 25 30 40 50 60 75
Input
Rated Input
Current (A)
< 460 V
HD1 (AC)
30.6 41.3 50.5 43.1 58.3 71.5 86.5
HD1 (DC)
37.5 50.5 61.9 52.8 71.4 87.5 106.0
ND1 (AC)
41.3 50.5 59.7 58.3 71.5 86.5 105
ND1 (DC)
50.5 61.9 73.2 71.4 87.5 106.0 129
≥ 460 V
HD2 (AC)
25.3 34.1 41.7 35.6 48.1 59.0 71.4
HD2 (DC)
31.0 41.8 51.1 43.7 59.0 72.3 87.5
ND2 (AC)
34.1 41.7 49.4 48.1 59.0 71.4 86.9
ND2 (DC)
41.8 51.1 60.4 59.0 72.3 87.5 106.0
