YASKAWA GA700 Series

Specifications
10
10.4 Model-Specific Specifications (400 V Class)
YASKAWA SIEPC71061705H GA700 Series Technical Manual 433
Model
Input
Voltage
Duty Rating 4031 4038 4044 4060 4075 4089 4103
Output
Rated Output
Capacity
(kVA)
< 460 V
*3
HD1
16 20 26 30 39 49 60
ND1
20 25 29 39 49 59 68
≥ 460 V
*4
HD2
17 22 27 32 41 52 61
ND2
22 27 32 41 52 61 76
Rated Output
Current (A)
< 460 V
HD1
24 31 39 45 60 75 91
ND1
31 38 44 59.6 74.9 89.2 103
≥ 460 V
HD2
21 27 34 40 52 65 77
ND2
27 34 40 52 65 77 96
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds The permitted frequency of overload is one time each 10
minutes.
• ND: 110% of the rated output current for 60 seconds The permitted frequency of overload is one time each 10
minutes.
Note:
Derating can be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 380 V to 480 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• AOLVand EZOLV: 120 Hz
• CL-V/f, CLV, AOLV/PM, and CLV/PM: 400 Hz
• V/f, OLV, OLV/PM: 590 Hz
Measures for
Harmonics
DC reactor External options Standard internal characteristics
Braking
Device
Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3, C3
Factory option
• Models 4xxxB: There is a category C3 EMC filter in the drive.
Power Supply
Rated Voltage, Rated Frequency
• Three-phase AC power supply 380 V to 480 Vat 50/60 Hz
• DC power supply 513 V to 679 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
< 460 V
HD1
24 33 40 34 46 57 69
ND1
33 40 48 46 57 69 84
≥ 460 V
HD2
21 28 35 30 40 49 59
ND2
28 35 41 40 49 59 72
*1 The maximum applicable motor output complies with 380 V motor ratings as specified in Annex G of IEC 60947-4-1. The rated
output current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 460 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*3 The rated output capacity is calculated with a rated output voltage of 380 V.
*4 The rated output capacity is calculated with a rated output voltage of 460 V.
Table 10.7 Rating (400 V Class)
Model
Input
Voltage
Duty Rating 4140 4168 4208 4250 4296 4371 4389
Maximum Applicable Motor
Output (kW)
< 460 V
*1
HD1
55 75 90 110 132 160 200
ND1
75 90 110 132 160 200 220
≥ 460 V
*2
HD2
55 75 90 110 150 185 220
ND2
75 90 110 150 185 220 260
Maximum Applicable Motor
Output (HP)
< 460 V
*1
HD1
75 100 125 150 175 200 250
ND1
100 125 150 175 200 250 300
≥ 460 V
*2
HD2
75 100 125 150 200 250 300
ND2
100 125 150 200 250 300 350
