12.8 H: Terminal Functions
844 YASKAWA SIEPC71061705H GA700 Series Technical Manual
A - H2-30
[Comparator 2 On-Delay Time]
B - H2-31
[Comparator 2 Off-Delay Time]
Figure 12.105 Comparator 2 Output Time Chart
Note:
The drive compares the monitors set with H2-26 as absolute values.
■ 69: External Power 24V Supply
Setting Value Function Description
69 External Power 24V Supply
The terminal activates when there is an external 24V power supply between terminals PS-AC.
ON : The external 24V power supply is supplying power.
OFF : The external 24V power supply is not supplying power.
■ 6A: Data Logger Error
Setting Value Function Description
6A Data Logger Error
The terminal activates when the drive detects a LoG [Com Error / Abnormal SD card].
■ 90 to 93: DWEZ Digital Outputs 1 to 4
Setting Value Function Description
90 to 93 DWEZ Digital Outputs 1 to
4
Sets the DriveWorksEZ digital output. Refer to the DriveWorksEZ online manual for more information.
■ A0 to A7: DWEZ Extended Digital Outputs 1 to 8
Setting Value Function Description
A0 to A7 DWEZ Extended Digital
Outputs 1 to 8
Sets the digital output for the DriveWorksEZ DO-A3 option card. Refer to the DriveWorksEZ online manual for more
information.
■ 100 to 1A7: Inverse Outputs of 0 to A7
Setting Value Function Description
100 to 1A7 Inverse Outputs of 0 to A7
Causes inverse output of the function for the selected MFDO. Uses the last two digits of 1xx to select which function to
inversely output.
For example, set H2-xx = 10E for the inverse output of E [Fault].
◆ H3: Analog Inputs
WARNING! Sudden Movement Hazard. Do test runs and examine the drive to make sure that the command references are
correct. If you set the command reference incorrectly, it can cause damage to the drive or serious injury or death.
Drives have three analog input terminals, terminals A1, A2, and A3. H3 parameters select the functions set to
these analog input terminals and adjust signal levels.
Table 12.69 shows the functions that you can set to analog input terminals. Use H3-02, H3-06, and H3-10 [MFAI
Function Selection] to set functions.
