YASKAWA GA700 Series

10.7 Drive Exterior and Mounting Dimensions
446 YASKAWA SIEPC71061705H GA700 Series Technical Manual
10.7 Drive Exterior and Mounting Dimensions
◆ Drive Models and Exterior and Mounting Dimensions
Note:
The estimated weights in this document are for drives with hardware revision D or later. For estimated weights of drives with hardware
revision C or earlier, contact Yaskawa or your nearest sales representative. The “REV” column on the nameplate on the right side of the
drive identifies the hardware revision. Refer to Nameplate on page 23 for more information.
Table 10.19 Three-Phase 200 V Class
Model
Ref.
IP20/UL Open Type IP20/UL Type 1
2004 - 2042 447 456
2056 448 457
2070, 2082 449 458
2110 450 459
2138 451 460
2169, 2211 452 461
2257, 2313 453 462
2360 454 463
2415 454 -
Table 10.20 Three-Phase 400 V Class
Model
Ref.
IP20/UL Open Type IP20/UL Type 1
4002 - 4023
447
456
4031, 4038 448 457
4044 - 4060
449
458
4075
450
459
4089, 4103 451
460
4140, 4168 452
461
4208 - 4296 453 462
4371 454 463
4389 454 -
4453 - 4675 455 -
