YASKAWA GA700 Series

Specifications
10
10.7 Drive Exterior and Mounting Dimensions
YASKAWA SIEPC71061705H GA700 Series Technical Manual 457
Table 10.48 Three-Phase 400 V Class (IP20/UL Type 1)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2 H0 H1 H2 H3 H4 t1 t2 d
4002
140
(5.51)
300
(11.81)
176
(6.93)
138
(5.43)
38
(1.50)
102
(4.02)
102
(4.02)
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
5
(0.20)
M5
4
(8.82)
4004
140
(5.51)
300
(11.81)
176
(6.93)
138
(5.43)
38
(1.50)
102
(4.02)
102
(4.02)
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
5
(0.20)
M5
4
(8.82)
4005
140
(5.51)
300
(11.81)
176
(6.93)
138
(5.43)
38
(1.50)
102
(4.02)
102
(4.02)
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
5
(0.20)
M5
4
(8.82)
4007
140
(5.51)
300
(11.81)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
5
(0.20)
M5
4.3
(9.48)
4009
140
(5.51)
300
(11.81)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
5
(0.20)
M5
4.3
(9.48)
4012
140
(5.51)
300
(11.81)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
5
(0.20)
M5
4.3
(9.48)
4018
140
(5.51)
300
(11.81)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
5
(0.20)
M5
4.6
(10.14)
4023
140
(5.51)
300
(11.81)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
5
(0.20)
M5
4.6
(10.14)
■ 2056, 4031, 4038
Figure 10.12 Dimension Diagram 2
Table 10.49 Three-Phase 200 V Class (IP20/UL Type 1)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2 H0 H1 H2 H3 H4 t1 t2 d
2056
180
(7.09)
340
(13.39)
202
(7.95)
134
(5.28)
68
(2.68)
140
(5.51)
140
(5.51)
300
(11.81)
284
(11.18)
8
(0.32)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
1.6
(0.06)
M5
7
(15.44)
Table 10.50 Three-Phase 400 V Class (IP20/UL Type 1)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D D1 D2 W1 W2 H0 H1 H2 H3 H4 t1 t2 d
4031
180
(7.09)
340
(13.39)
202
(7.95)
134
(5.28)
68
(2.68)
140
(5.51)
140
(5.51)
300
(11.81)
284
(11.18)
8
(0.32)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
1.6
(0.06)
M5
6.5
(14.33)
4038
180
(7.09)
340
(13.39)
202
(7.95)
134
(5.28)
68
(2.68)
140
(5.51)
140
(5.51)
300
(11.81)
284
(11.18)
8
(0.32)
40
(1.57)
1.5
(0.06)
1.6
(0.06)
1.6
(0.06)
M5
6.5
(14.33)
