Parameter List
11
11.9 F: Options
YASKAWA SIEPC71061705H GA700 Series Technical Manual 511
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F3-24
(0BF1)
Expert
Terminal DE Function
Selection
Sets the function for terminal DE of the DI-A3 option when F3-01 = 8 [Digital Input
Function Selection = Multi-Function Digital Input].
F
(1 - 19F)
772
F3-25
(0BF2)
Expert
Terminal DF Function
Selection
Sets the function for terminal DF of the DI-A3 option when F3-01 = 8 [Digital Input
Function Selection = Multi-Function Digital Input].
F
(1 - 19F)
772
◆ F4: Analog Output Option
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F4-01
(0391)
Terminal V1 Function
Selection
Sets the monitor signal output from terminal V1.
Set the x-xx part of the Ux-xx [Monitor]. For example, set F4-01 = 102 to monitor U1-
02 [Output Frequency].
102
(000 - 999)
773
F4-02
(0392)
RUN
Terminal V1 Gain
Sets the gain of the monitor signal that is sent from terminal V1. Sets the analog signal
output level from the terminal V1 at 10 V or 20 mA as 100% when an output for
monitoring items is 100%.
100.0%
(-999.9 - +999.9%)
773
F4-03
(0393)
Terminal V2 Function
Selection
Sets the monitor signal output from terminal V2.
Set the x-xx part of the Ux-xx [Monitor]. For example, set F4-03 = 103 to monitor U1-
03 [Output Current].
103
(000 - 999)
773
F4-04
(0394)
RUN
Terminal V2 Gain
Sets the gain of the monitor signal that is sent from terminal V2. Sets the analog signal
output level from terminal V2 at 10 Vor 20 mA as 100% when an output for monitoring
items is 100%.
50.0%
(-999.9 - +999.9%)
774
F4-05
(0395)
RUN
Terminal V1 Bias
Sets the bias of the monitor signal that is sent from terminal V1. When an output for
monitoring items is 0%, this parameter sets the analog signal output level from the V1
terminal as a percentage of 10 V or 20 mA.
0.0%
(-999.9 - +999.9%)
774
F4-06
(0396)
RUN
Terminal V2 Bias
Sets the bias of the monitor signal that is sent from terminal V2. Set the level of the
analog signal sent from the V2 terminal at 10 Vor 20 mA as 100% when an output for
monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
774
F4-07
(0397)
Terminal V1 Signal
Level
Sets the output signal level for terminal V1.
0 : 0 to 10 V
1 : -10 to 10 V
0
(0, 1)
774
F4-08
(0398)
Terminal V2 Signal
Level
Sets the output signal level for terminal V2.
0 : 0 to 10 V
1 : -10 to 10 V
0
(0, 1)
774
◆ F5: Digital Output Option
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F5-01
(0399)
Terminal P1-PC
Function Select
Sets the function of terminal P1-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3
Output Mode Selection = Programmable (F5-01 to F5-08)] to enable this function.
0
(0 - 1A7)
776
F5-02
(039A)
Terminal P2-PC
Function Select
Sets the function of terminal P2-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3
Output Mode Selection = Programmable (F5-01 to F5-08)] to enable this function.
1
(0 - 1A7)
776
F5-03
(039B)
Terminal P3-PC
Function Select
Sets the function of terminal P3-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3
Output Mode Selection = Programmable (F5-01 to F5-08)] to enable this function.
2
(0 - 1A7)
776
F5-04
(039C)
Terminal P4-PC
Function Select
Sets the function of terminal P4-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3
Output Mode Selection = Programmable (F5-01 to F5-08)] to enable this function.
4
(0 - 1A7)
776
F5-05
(039D)
Terminal P5-PC
Function Select
Sets the function of terminal P5-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3
Output Mode Selection = Programmable (F5-01 to F5-08)] to enable this function.
6
(0 - 1A7)
776
F5-06
(039E)
Terminal P6-PC
Function Select
Sets the function of terminal P6-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3
Output Mode Selection = Programmable (F5-01 to F5-08)] to enable this function.
37
(0 - 1A7)
776
