12.7 F: Options
776 YASKAWA SIEPC71061705H GA700 Series Technical Manual
■ Digital Output Card Selection
Refer to “H2: Multi-function Digital Output” for more information about the functions that output from the
terminals when F5-09 = 2 [DO-A3 Output Mode Selection = Programmable (F5-01 to F5-08)]. Use F5-01 to F5-
08 to set the output items.
No. Name Setting Range Default
F5-01 Terminal P1-PC Function Select 0 - 192 0: During Run
F5-02 Terminal P2-PC Function Select 0 - 192 1: Zero Speed
F5-03 Terminal P3-PC Function Select 0 - 192 2: Speed Agree 1
F5-04 Terminal P4-PC Function Select 0 - 192 4: Frequency Detection 1
F5-05 Terminal P5-PC Function Select 0 - 192 6: Drive Ready
F5-06 Terminal P6-PC Function Select 0 - 192 37: During Frequency Output
F5-07 Terminal M1-M2 Function Select 0 - 192 F: Not Used
F5-08 Terminal M3-M4 Function Select 0 - 192 F: Not Used
■ F5-01: Terminal P1-PC Function Select
No.
(Hex.)
Name Description
Default
(Range)
F5-01
(0399)
Terminal P1-PC Function
Select
Sets the function of terminal P1-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3 Output Mode
Selection = Programmable (F5-01 to F5-08)] to enable this function.
0
(0 - 1A7)
■ F5-02: Terminal P2-PC Function Select
No.
(Hex.)
Name Description
Default
(Range)
F5-02
(039A)
Terminal P2-PC Function
Select
Sets the function of terminal P2-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3 Output Mode
Selection = Programmable (F5-01 to F5-08)] to enable this function.
1
(0 - 1A7)
■ F5-03: Terminal P3-PC Function Select
No.
(Hex.)
Name Description
Default
(Range)
F5-03
(039B)
Terminal P3-PC Function
Select
Sets the function of terminal P3-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3 Output Mode
Selection = Programmable (F5-01 to F5-08)] to enable this function.
2
(0 - 1A7)
■ F5-04: Terminal P4-PC Function Select
No.
(Hex.)
Name Description
Default
(Range)
F5-04
(039C)
Terminal P4-PC Function
Select
Sets the function of terminal P4-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3 Output Mode
Selection = Programmable (F5-01 to F5-08)] to enable this function.
4
(0 - 1A7)
■ F5-05: Terminal P5-PC Function Select
No.
(Hex.)
Name Description
Default
(Range)
F5-05
(039D)
Terminal P5-PC Function
Select
Sets the function of terminal P5-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3 Output Mode
Selection = Programmable (F5-01 to F5-08)] to enable this function.
6
(0 - 1A7)
■ F5-06: Terminal P6-PC Function Select
No.
(Hex.)
Name Description
Default
(Range)
F5-06
(039E)
Terminal P6-PC Function
Select
Sets the function of terminal P6-PC on the DO-A3 option. Set F5-09 = 2 [DO-A3 Output Mode
Selection = Programmable (F5-01 to F5-08)] to enable this function.
37
(0 - 1A7)
